Dingchen Complete Plant Newspaper A4 Paper Making Machine (1575mm 10tpd)

Product Description

Dingchen Complete Plant Newspaper A4 Paper Making Machine (1575mm 10tpd)

Technical parameter:

1	Raw material	wheat straw pulp,reed pulp
2	Output paper	A4 Cultural paper
3	Paper weight	70-80gsm
4	Net paper width	1600mm
5	Wire width	1950mm
6	Capacity	10T/D
7	Working speed	90-100 m/min
8	Design speed	50-150m/min
9	Rail gauge	2400mm
10	Drive way	Alternating current frequency conversion adjustable speed, section drive

Note:
Financial Analysis can be provided if customers' need to compare with cost of different Raw Materials.

Tips

Different model has different specifications
If customer want to get a quotation as soon as possible, please provide the following information for us :
1.Output paper type;
2.Capacity(tons/24hours);
3.Output paper weight(gram/m2);
4.Raw material
Main equipment structure:
1.Fourdrinier wire section:10.83m×1950mm fourdrinier wire 1 set;Φ450mm×2400mm vacuum couch roll 1 set; forming table wrapped by stainless steel, headbox made by (304) stainless steel .
2.Press section: Φ650 natural marble roll 2 sets,Φ600mm×1950mm rubber roll 2 sets, rubber shore hardness 95ºC±2. .
3.Dryer section: Φ1500mm×1950mm×2400mm alloy dryer can 6 sets, first and second can chroming. With Dry felt device, blade 6 sets,semi-closed dryer exhaust hood 1 set.
4.Calender section:3 rolls calender 1 set,bottom roll Φ300mm,middle roll Φ300mm,top roll Φ350mm
5.Winding section:with 1600mm Horizontal pneumatic rewinding machine 1 set,winding drum Φ900mm×1900mm×2400mm.
6.Rewinding section:with 1600mm frame-style rewinder 1 set,(overfeed)
7.Cutting section:with 1600 heavy-duty single cutter 1 set.

Company Information
Zhengzhou Dingchen Machinery Co., Ltd., located in Central China, is a professional machinery manufacturer focusing on the R&D and production of paper making machines.Our products include paper making machines,pulp making machine,parts and paper converting machines such as kraft paper machines,corrugated paper machines,tissue/toilet paper machines,office paper machines, newspaper machines and so on. Our factory gathers and trains many essential technicians and management system to ensure all products meet the quality of ISO and update constantly!
Our products have been exported to many countries and regions, such as America, Egypt, India, Fiji, Iran, Ghana ,Paraguay, Russia, Syria,Pakistan, Tanzania, and Uzbekistan. Our products and services have won customers' consistent affirmations.have won customers' consistent affirmations.We have a large scale of products regarding paper machinery, including:A.Pulping equipment (D-type hydrapulper, cleaner, DD refiner, pressure screen, screen basket, pulp pump etc.)B.Paper machinery (Tissue/Toilet paper machine, Multi-fourdrinier paper machine, head box, cylinder mould, dryer cylinder, roller etc.) C.Paper making finished devices (Paper calender, pope reel,size press, paper rewinder etc.)Meet customers' requirements and exceed customers' expects.We wish to found long-termcooperation with your companyTechnical Advantage 1.Experienced producing team2.Advanced technological strengthProduct Advantage 1.Through the international authentication2.The same material the most preferential price3.A lot of varieties for the customer to chooseService Advantage 1.Technical consultation2.Project evaluation3.Detailed design of factory4.Installing and testing the whole production line5.Training engineers and workers6.Supplying spare parts for long timeThe business process1.send your requirements:raw material,capacity,paper grammage2.we make the solution to you3.come visit and negotiate4.sign contract5.first payment6.production7.pay spare money8.delivery9.installation ,training,test run10.production consultlation Packaging & Shipping
