| Truck Brand | SINOTRUK-HOhan | |||
| Driving Type | LHD or RHD | |||
| Dimension(Lx W xH)(unloaded)(mm) | 12,000x2496x3450 | |||
| Working body size (L*W*H, mm) | 9000x2300x1500,Optional: tipper,cargo, tanker, flatbed, mixer etc. | |||
| Cargo body thickness(mm) | bottom:8mm, side:6mm | |||
| Engine Model (Steyr technology, made in China) | Fuel type | Diesel | ||
| | Horse Power, max(kw/rpm) | Optional,420hp | ||
| | Emission | EURO II III IV V | ||
| | Model | WD615. water-cooled,four strokes,6 cylinders in line with water cooling,directly injection | ||
| Transmission | Model | HW19710,10 forwards and 2 reverse | ||
| Brake system | Service brake | Dual circuit compressed air brake | ||
| | Parking brake | spring energy, compressed air operating on rear wheels | ||
| | Auxiliary brake | Engine exhaust brake | ||
| Steering system | Model | ZF8118 hydraulic steering with power assistance | ||
| Front axle | HF9, Steering with double T-cross section beam Loading capacity: 9000kg | |||
| Rear axle | HC16, Pressed axle housing, central double reduction with differential locks between axles and wheels Ratio:3.93/4.42/4.80/5.73 | |||
| Color | Optional | |||
| Tire | 12R20 Radial tires or 12R22.5 Tubeless tyre | |||
| Tire quantity | 10+1 or 12+1 | |||
| Electrical system | Battery | 2X12V/165Ah | ||
| | Alternator | 28V-1500kw | ||
| | Starter | 7.5Kw/24V | ||
| Cab | Optional: HW76 or 79 cabin, one or two sleepers with A/C | |||
