Robust Self-Propelled Rice Harvester Machine with Yuchai 360HP Engine

Product Description

Product Parameters

Model		4LZ-18
Horsepower		Yuchai 360HP
Drive type		4WD
Dimension(L*W*H)(mm)		10500*8500*3950
Weight(kg)		15500
Cutting width (mm)		7600-8500
Production efficiency	Productivity(hm²/h)	1.0-3.5
	Fuel tank capacity(L)	600
	Working speed (km/h)	4-10
	Feeding speed(kg/s)	18
Thresher	Grain tank(m³)	11.5
	Max unload height(mm)	4800
	Grain unloading drum height(mm)	5700
	Threshing pattern	Vertical axial flow rod tooth type
	Sorting method	Reciprocating vibrating screen+Centrifugal fan
Chassis	Wheel base(mm)	3845
	F/R wheel space(mm)	F:2800/R:2700
	Tyre model(F/R)	F:800/65R32 R:540/65R28

Detailed Photos
Model 4LZ-18 This state-of-the-art self-propelled wheat harvester, model 4LZ-18, incorporates advanced longitudinal axis flow roller separation technology. It is meticulously engineered to primarily harvest wheat and rice, ensuring maximum efficiency and productivity.
With the versatility of replacing specific parts, this harvester can seamlessly transition to harvest soybeans, various other grains, and even corn kernels, making it an indispensable tool for a diverse range of agricultural needs.


Product Description
In-Depth Technical Specifications for Model 4LZ-18
Featuring an expansive working width ranging from 7.6 to 8.5 meters and a high-capacity feeding rate of 18 kg/s; Equipped with a robust Yuchai 360 horsepower engine, offering the flexibility for drivers to select different power outputs tailored to the specific crops being harvested, thereby maximizing energy efficiency and fuel economy; All tires are designed with enlarged, wide, high-pattern treads, providing excellent adaptability to diverse terrains including sandy, muddy, and slippery land; Built with a durable four-wheel drive system. The front drive employs a static hydraulic mechanism for effortless operation. Featuring the 1000 series front axle and a heavy-duty four-wheel drive rear axle, this machine boasts superior load-bearing capacity and exceptional roadability; Enhanced with an elongated fish scale screen to expand the cleaning area. The quick-change concave screen panels facilitate rapid swapping of the cutting header and threshing components, enabling efficient harvesting of various crops such as wheat, corn, soybeans, and sorghum, truly embodying versatility in one machine; The heavy-duty high-low gearbox, paired with a continuously variable speed disk, allows for adaptive roller speed adjustments from 300 to 1100 RPM. Utilizing American Peer spherical bearings throughout the vehicle ensures robust load-bearing capabilities and prolonged service life. The transmission belt is a durable black one-tooth design, offering strong tension and excellent heat dissipation, ideal for extended and large-scale operations; The high-end large-longitudinal axis flow harvester is equipped with a cutting header bridge that features a reverse function, simplifying the process of clearing blockages from the bridge and cutting table; The grain tank can be effortlessly raised and lowered through a hydraulic one-button operation, allowing the driver to easily open and close the grain bin cover via an electric control button. Company Profile
Shandong King Machinery Co., Ltd. is a distinguished national high-tech enterprise dedicated to the relentless pursuit of excellence in the research, development, manufacturing, and export of premier agricultural machinery. Our extensive product range includes top-tier corn harvesters, advanced grain combine harvesters, state-of-the-art soybean harvesters, efficient peanut harvesters, and robust rice harvesters. Additionally, we offer high-performance tractors and indispensable agricultural auxiliary tools, ensuring we meet and exceed the varied needs of the agricultural sector.
Spanning an impressive 300,000 square meters and employing nearly 1,000 dedicated professionals, Shandong King Machinery Co., Ltd. brings over 30 years of unmatched experience in agricultural machinery production. Our unwavering commitment to quality service has propelled our products to more than 30 countries and regions, including Russia, South America, Central Asia, Southeast Asia, and Africa. Boasting over 70 scientific and technological invention patents, our robust management and R&D capabilities drive continuous innovation and customer-centric design. We craft diverse models that have garnered accolades from both domestic and international clients, thanks to our superior product quality, autonomous R&D prowess, and impeccable after-sales service. Embodying the ethos of 'Serve customers and make progress together,' we pledge to persistently excel in agricultural machinery, offering unparalleled products and services globally. Our mission is to provide farmers with the ultimate planting support, spearheading advancements in agricultural machinery, and establishing ourselves as the unrivaled KING in this domain.
Utilizing the pinnacle of advanced technology, we ensure unparalleled excellence in every product we deliver.
Our extensive array of choices caters impeccably to the diverse and unique needs of our valued customers.
Our sophisticated technical team offers the most timely and professional services, ensuring your technical needs are always met with precision and expertise.

Our Advantages
It's not just the price that captures the market,
but the unparalleled quality that we deliver.
It's not mere words that resonate with people,
but our unwavering integrity that earns their trust.
It's not fleeting discounts that retain our customers,
but the powerful word of mouth that speaks volumes about our excellence.
Certifications
PERFECT TECHNOLOGY GIVES YOU FULL SATISFACTION
Our confidence stems from our cutting-edge technology and innovative solutions.

---
