Mini 2.5t Cooking Gas Filling Station LPG Tank Skid 5000L LPG Tanker Station 5m3 LPG Gas Station

Product Description

Mini 2.5t Cooking Gas Filling Station LPG Tank Skid 5000l lpg Tanker Station 5m3 lpg Gas Station
Product description for lpg gas station:
1)lpg skid station capacity
5,000l , 10,000l, 15,000l, 20,000l, 25,000l, 30,000l, 35,000l, 50,000l, 80,000l, 100,000l . 120,000l, 150,000l, 180,000l, 200,000l.
2)lpg tank skid material
Q345R Q370R SA516 16MnR
3)lpg tank skid production flow
cuttings-bending plate-submerged arc welding-assembly-non destructive testing-heat treatment- hydraulic test- sand blasting-painting
4)Main parts of lpg tank skid
pump, motor, compressor, cut-off valve, safety valve, alarm system, lpg dispenser or filling scale, water spraying system or sunshade, magnetic level gauge (rochester gauge), rotor gauge, temperature gauge, pressure gauge, lpg skid control panel, mass flow meter...
5) opeeation details for the lpg tank skid:
*Feeding gas to transport vehicles: high quality dispenser is equipped and its measurement is accurate and stable.
*Unloading: The LPG tank truck can unload the medium to the storage tank on the skid-mounted plant smoothly
*Drainage: The sundries like water-logging in the storage tank will e drained through the drain outlet.
*Emptying:The residual pressure in storage tank can be released through the emptying port during overgauling.
*Alternative Pumps: Under fault condition, gas filling pump and unloading pump can be mutually alternative.
*Reverse unloading:The liquid on the storage tank can be unloaded to the gas tank car and delivered.
*Emergency cut-off :Air-operated emergency cut-off valve is installed a the liquid outlet on the storage tank, by which the emergency cut-off under abnormal conditions can be achieved.
*Leakage Alarm: Leakage probes are installed in the key positons of the skid-mounted gas station, so as to dect the equipment's security status.
*LIquid Level Alarm: Upper and lower liquid level limit switch are installed. Therefore, it has liquid alarm and control function.
Parameters for the lpg tank skid station:

Parameters of 10cbm LPG tank
Item		Parameters
Tank	Volume of the tank	10 CBM
	Overall dimensions of tank (mm)	5260*1620*2210
	Diameter (mm)	1600
	Curb weight(kg)	2950
	Filling weight(kg)	5000
	Cylinder thickness (mm)	10
	Head thickness (mm)	10
	Design pressure	1.77MPa
	Max working pressure	1.61MPa
	Design temperature	≤50ºC
	Filling medium	Liquid petroleum gas (propane)
	Corrosion allowance (mm)	1.0
	Thermal treatment	The entirety
	Filling capacity	420~540kg/CBM
	Material of the tank	Q345R
	Hydraulic test pressure	2.22 M Pa
	Gas tight test pressure	1.77 M Pa
	Service time	15 years

Accessories list of lpg tank
Parts No	Size	Parts Name	Model No.
a	DN50	Cut-off Valve for Drain Outlet	J41N-2.5-50
b	DN80	Cut-off Valve for Liquid Phase Outlet	J41N-2.5-80
c1	DN50	Cut-off Valve for Gas Phase Balance Outlet	J41N-2.5-50
c2	DN50	Cut-off Valve for Gas Phase Balance Outlet	J41N-2.5-50
d	DN80	Cut-off Valve for Liquid Inlet	J41N-2.5-50
i	DN50	Cut-off Valve for Air Drain Outlet	J41N-2.5-50
f1 / f2	DN25	Magnetic Level Gauge	J41N-2.5-25
e	M33*2	Thermometer	WTQ-280
g	M20*1.5	Pressure Meter	Y-100T
/	/	Ball floating Level Meter	HG21584-95
h	DN80	Safety Valve	A42F-25
j	DN450	Manhole	HG20592-WN
Remark	The f1, f2 is the Magnetic Level Gauge. But the Ball Floating Level Meter is recommended for you.

Key accessories for lpg gas Skid Station

LPG Pump&Motor for discharging LPG from LPG Tank Truck to LPG Tank Skid	Medium:Liquid petroleum gas Speed:15m3/h Input and Output Diameter:50 mm Working pressure:2.0 Mpa Working temperature:-40ºC- 50ºC Material:carbon steel		Unit	1
	Revolving speed:1470 r/min Power:5.5 kw Voltage:380 V Protection grade:ExdIIBT4		Unit	1
LPG Filling Scale	Power: 220V, 30W Weighing Platform Size: 535 x 425mm Scale Capacity: 2kg to150kg Working Temperature: -40ºC~50ºC Working Pressure: 1.6MPa Automatically Filling & Cut-off, Cylinder Tare Weight Deduction, Explosion-proof Indication: Exdmeib AT3 3500 Filling Records Available for verification		Unit	1
Permanent Gas Detector(Leak detectors)	Measuring Range: 0~100% LEL Precision: <±5%(F.S.) Size: 180*140*95mm Nozzle: M20*1.5 Signal Transmission Distance: ≤1200M Weight: 1.5kg Warning Method: Controller warning(>70dB) Ex-Proof: Ex ID IIC T6		Unit	1
Floating ball level gauge	Cam show the liquid level inside the tank		Piece	1
One Set accessories needed for tank skid	Tank safety valve, Emergency shut off valve, Safety reverse valve, Check valve, ball valve, Pressure gauge with Needle valve, Temperature gauge, Shock-proof pipe, L/U-tube, Flange, Metal gasket, bolt with nut, Steel pipeline, Bottom Base.	/	Set	1
Water spraying system	Can spray water to cool the lpg tank		Set	1

Details for the lpg tanker gas station:
About our company 1. Hubei Chusheng Vehicle is a famous and the biggest manufacturer with very professional experience in special automobile field for more than 15 years in China. We have more than 3000 workers, 400 technicians, and factory scale is more than 690,000m2.
2. Our most advantage and leading products including LPG tanker series, Water Tank, Fuel tank, Refrigerated Truck, Garbage Truck, Towing/Wrecker truck, Dump Truck, Sewage Suction Truck, Concrete Mixer Truck, Bulk Cement Truck, Van Truck, Sweeper Truck, Truck with Crane, Fire fighting Truck, High-altitude Operation Truck, Chemical Liquid Truck, Milk Transport Truck, LED Display Truck, Various Semi-trailer, Spare parts etc.
3. We have successfully exported to more than 60 countries, such as Ghana, Togo, Sudan, Kuwait, Peru, Nigeria, Benin, Angola, Tajikstan, Azerbaijan, Namibia, Burma, Korea, Iran, Afghanistan, Iraq, Philippines, Vietnam, Saudi Arabia, Mexico, Chile, Bolivia, Tanzania, Zambia, Zimbabwe, Yemen etc.
We have strict quality control of raw material, professional management team and technical workers, advanced equipments, strict inspection before delivery, excellent packing and shipping team.
Other product series of lpg skid station:
Contacts of lpg gas station:
For more products information, please contact:
Lucy Wang
Sales Manager
Xiagong Chusheng (Hubei) Special Purpose Vehicle Manufacturing Co., Ltd.
Factory: NO.9, Jiliang Avenue, Suizhou Economic Development Zone,Suizhou,Hubei,China
Office: Room 1108, Eurasia Plaza,No.20 Jinyinhu Road, East- west lake District,Wuhan,Hubei,China.


Web:csctruck.en.made-in-china.com
