| US$5,000.00-6,100.00 | 1 Piece (MOQ) |
| Model | unit | XZ6326B |
| Table size | mm | 1120X260 |
| T slot no./width/distance | no | 5/14/50 |
| Max. load of Table | kg | 200 |
| table Longitudinal travel(manual/auto) | mm | 600 |
| table Cross travel (manual) | mm | 300 |
| table Vertical travel(manual) | mm | 380 |
| Spindle taper | ISO40 | |
| spindle speed /step -- Vertical | rpm | 67-2010/12steps |
| --Horizontal | rpm | 40-1300/12steps |
| Max.drilling dia. | mm | 30 |
| Max.end milling width | mm | 125 |
| Max. vertical milling Dia. | mm | 25 |
| Max.tapping dia. | mm | M16 |
| quill travel | mm | 120 |
| swivel angle of headstock | degree | ±45º |
| vertical spindle axis to column surface | mm | 220-760 |
| vertical spindle nose to table surface | mm | 115-430 |
| horizontal spindle axis to table surface | mm | 0-380 |
| horizontal spindle axis to ram bottom | mm | 175 |
| ram travel | mm | 520 |
| Longitudinal feed | mm / min | 24-720/8steps |
| Longitudinal rapid speed | mm / min | 1040(X) |
| automatic spindle feed | 0.1/0.15/0.3 | |
| main motor | kw | 1.5/2.2(V),2.2(H) |
| feed motor | kw | 0.37(X) |
| coolant motor | kw | 0.04 |
| overall dimension | cm | 158X145X215 |
| N/W,G/W | kg | 1350/1500 |
| Drill chuck |
| Reduction sleeve |
| Draw bar |
| X,Y axis auto power feed |
| Z axis motorized lifting |
| Mill arbors |
| Collet chuck kits |
| Coolant system |
| Chip tray |
| Work lamp |
| Tools and box |
| 3 axis DRO |
| Air draw bar |
| 58 pcs Clamping kits |
| Spindle protection |
| Worktable protection |
| Rotary table HV10 |
| Dividing head F11-160A |
| Machine vice 160mm |
