Product Details
Product Description
Product Description
Refueling Truck is a vehicle for transporting oil materials.It's a Mobile Oil Station Supplying to Trucks & Cars ，The filling machine can be installed in the front part of the tank or in the lower part of the truck body. We Can supply different chassis brand, such as Dongfeng, Sinotruk, FORLAND, FOTON, JAC, ISUZU, FAW, Tanker volume is from 3m³ to 35m³.
3 tons to 5 tons of small oil tanker is the best selling truck, for the shuttle and the construction site between the country flexible and convenient oil depot closer to the refueling point, 6 to 9 tons is generally suitable for engineering machinery a little more than a little more than a little more, more than 9 tons is generally suitable for refueling points far away from the distance factory distance, there are more than 9 tons of cars.When you choose a tanker, customers must choose the most suitable tonnage vehicle according to their own conditions.
Advantage
Specifications
The advantage of 4X2 Foton 8 CBM Mobile Fueling Trucks
1.Oil Filling Display in Liter, Price & Amount.
2.Automatic Oil Filling & Shut-off Controlled Computer.
3.Galvanized Steel Filling Gun with Rust Proof.
4.Hose Length Can be Made as Per Request.
5.Explosive Proof Design Supply to International Oil Company.
The specification of4X2 Foton 8 CBM Mobile Fueling Trucks
Item No.
| Parameters
|
Overall Dimension
| 6525×2052×2160(mm
|
Gross Vehicle Weight
| 11495kg
|
Curb weight
| 4000 kg
|
Loading Weight
| 7495 kg
|
Wheel Base
| 3650 mm
|
Wheel track (front/rear)
| 1130 /1745 mm
|
Approach/Departure
angle(°)
| 21/17
|
Engine
| Chaochai CY4102-C3F
|
Engine horsepower
| 95 HP Euro III
|
Displacement
| 3.856L(Diesel)
|
Cabin
| 3passengers
|
Max Driving Speed
| 95km/h
|
Type
| 4-cylinder in-line with water cooling，turbo-charging and inter-cooling
|
Full loading Fuel
Consumption Rate
| ≤210g/kW.h
|
Rated speed
| 3200rpm
|
Tire
| 7.00R16，6pieces
|
Tank Capacity
| 8 cubic meters
|
Tank Material
| Q235 High Tension Steel, 6mm Thick Carbon Steel, Ball Valve for gravity
discharging,Emergency Cut Off valve.Customized Tank Color, Can also
Paint Customer's Logo or Advertisement on Tank
|
Compartments
| 2-3
|
Oil dispenser device
| 1.Pump, Dispenser, Filling Guns All in Only Unit
2.Oil Filling Hose & Gun
|
>>
