| Same design, different sizes | ||||||
| Model No. | Exterior Dimension | Interior High | Wire Guage | Grid Size | Loading Capacity | Loaded in 1x40'GP |
| LxWxH(mm) | mm | mm | mm | kg | sets | |
| JM-CP001 | 1200x800x1000 | 850 | ¢5-¢12 | 60x103 | 800 | 480 |
| JM-CP002 | 1000x1200x1450 | 1300 | ¢5-¢10 | 60x105 | 1000 | 280 |
| JM-CP003 | 1200x1000x1200 | 1200 | ¢5-¢10 | 60x105 | 800 | 460 |
| JM-CP004 | 1200x1000x1000 | 1000 | ¢5-¢10 | 60x105 | 800 | 480 |
| JM-CP005 | 1200x800x1000 | 1000 | ¢5-¢10 | 60x105 | 800 | 480 |
| Material | Mild steel Q235 | |||||
| Application area | Warehouse, logistic, mass retail, recycling industry, etc. | |||||
| Finish | Zinc/hot dip galvanized/powder coating | |||||
| Remark | Costomized or OEM support | |||||
| Main Features | 1.Collapsible-save space when not in use,ideal for return journeys 2.Bright electro zinc plated finish 3.Standard half-hinged gate access 4.Long lasting,economical alternative to disposable packing 5.Open wire mesh design allows for full visibility for inventory checks,ventilation and cleaness. 6.Four-way entry for easy use with lift trucks | |||||
