HOPERF Bluetooth 5.2 / IEEE 802.15.4 System on Chip CMT4522

Product Details

Product Description

Product Description
Description:
CMT4522 is a System on Chip (SoC) for Bluetooth 5.2 / IEEE 802.15.4 applications. It has ARM® Cortex™- M0 32-bit processer with 64K retention SRAM, 128KB-8MB flash, 96KB ROM, 256bit efuse, and an ultralow power, high performance, multi-mode radio. Also, CMT4522 can support BLE / IEEE 802.15.4 with security, application and over-the-air download update. Serial peripheral IO and integrated application IP enables customer product to be built with minimum bill-of-material (BOM) cost.
Features:
• ARM® Cortex™-M0 32-bit processor with SWD
• Memory
 128KB-8MB in-system flash memory
 64KB SRAM, all programmable retention in sleep mode
 4-way instruction cache with 8KB Cache RAM
 96KB ROM
 256bit efuse • 22 general purpose I/O pins
 GPIO status retention in off/sleep mode
 configurable as serial interface and programmable IO MUX function mapping
 All pins can be configured for wake-up
 All pins for triggering interrupt
 3 quadrature decoder(QDEC)
 6-channel PWM
 2-channel PDM/I2C/SPI/UART
 4-channel DMA
• DMIC/AMIC with microphone bias
• 8-channel 12bit ADC with low noise voice PGA
• 6-channel 32bit timer, one watchdog timer
• Real timer counter (RTC)
• Power, clock, reset controller
• Flexible power management
 Operating Voltage range 1.8V to 3.6V
 Embedded buck DC-DC and LDOs
 Battery monitor
• Power consumption
 0.3μA @ OFF Mode(IO wake up only)
 1μA @ Sleep Mode with 32KHz RTC
 13uA @ Sleep Mode with 32KHz RTC and all SRAM retention
 Receive mode: 4mA @3.3V power supply
 Transmit mode: 4.6mA(0dBm output power) @3.3V power supply  MCU: <60uA/MHz
• RC oscillator hardware calibrations
 Internal High/Low frequency RC osc
 32KHz RC osc for RTC with +/-500ppm accuracy
 32MHz RC osc for HCLK with 3% accuracy
• High Speed Throughput  Support BLE 2Mbps Protocol
 Support Data Length Extension
 Throughput up to 1.6Mbps(DLE+2Mbps)
• AoA/AoD Direction Finding
• Support SIG-Mesh Multi-Feature
 Friend Node  Low Power Node
 Proxy Node  Relay Node
• 2.4 GHz transceiver
 Compliant to Bluetooth 5.2
 Sensitivity: -99dBm@BLE 1Mbps data rate -105dBm@BLE 125Kbps data rate -103dBm@IEEE 802.15.4 250Kbps data rate
 TX Power -20 to +10dBm in 3dB steps
 Single-pin antenna: no RF matching or RX/TX switching required
 RSSI (1dB resolution)
 Antenna array and optional off-chip RF PA/LNA control interface • AES-128 encryption hardware • Link layer hardware
 Automatic packet assembly
 Automatic packet detection and validation
 Auto Re-transmit
 Auto ACK
 Hardware Address Matching
 Random number generator
• Operating temperature:  -40˚C ~+85 ˚C (Consumer)  -40 ˚C ~+105 ˚C (Industrial)
• RoHS Package: QFN32(4mm x 4mm)
• Applications: wearables, beacons, home and building, health and medical, industrial and manufacturing, retail and payment, data transmission, PC/mobile/TV peripherals, internet of things (IoT)

---
