Plastic Machine/Powder Mixer/PVC Mixing Machine/Mixing Machine/Plastic Mixing Machine/Chemical Mixer/Vacuum Conveyor/Conveyor System/Blender/Liquid Mixing Tank

US$4,000.00-10,000.00 1 set (MOQ)

Basic Info.

Model NO.
CY
Application Area
Chemical, Chemical
Condition
New
Stirring Type
Spiral
Working
High Speed Mixer
Voltage
380V/50Hz/3phase, According to Requirement
Model Number
Shr-500A
Power(W)
7.5/5.55kw
Main Electrics
Siemens
Mixer Type
Powder Mixer
Layout Type
Verticle
Operating type
Cycle Operating
Transport Package
Wood Pallet+Stretch Film Package
Specification
depends
Trademark
CHIYU
Origin
Jiangsu Suzhou
HS Code
8477800000
Production Capacity
50sets/Month

Product Description

Application&Features:
For plastic, rubber, daily chemical and other industries of various materials mixing, stirring, drying, coloring and other process.
1.It is the basic equipment of plastic extrusion production line .
2.Two layers of sealing are adopted in the cover of the mixer and opened in pneumatic mode.The cooling mixer is a vaulted lid, not easy to take shape.
3.The blades have been passed the test of the dynamic and static balance testing machine.
4.Barrel wall undergoes precise grinder.
Main Technical Parameters:
Item
Model		 Total
volume(L)		 Effective
volume(L)		 Rotating Speed
(r/min)		 Motor power
(kw)		 Mixing time
(min.)
SHR-100 100 75 650/1300 14/22 <=10
SHR-200 200 150 475/950 30/42 <=10
SHR-300 300 225 475/950 40/55 <=10
SHR-500 500 375 430/860 55/75 <=10
SHR-800 800 600 357/714 83/110 <=10
SHR-1000 1000 750 325/650 110/160 <=10
SHR-1500 1500 1100 250/500 160/220 <=10

Scene Pictures:
