600-800kg/H Farm Use Rice Husk Animal Feed Mill Production Line

Product Description

✠ CE Approved Poultry Pellet Mill for Sale ✠
Feeding your animals with pellets has been proven to be of significantly advantageous since it will help your animals in easy digestion of the food given to them and also help in increasing level of yielding capacity. To extrude these pellets from the raw/crude stocks found in the farm, one need to have a sizeable poultry pellet mill. And we strongly recommend this poultry pellet mill for small to medium feed pellet manufacturer.

▸Overview of ABC Machinery STLP Poultry Pellet Mill

▸Title
▮ Technical parameters of STLP pellet mill

Model	Power (Kw)	Capacity (kg/h)	Pellet Size (mm)	Weight (kg)	Dimension (mm)
STLP300	45.7	600-800	2~8mm	2464	15000*4000*4500
STLP400	61.2	800-1000	2~8mm	2902	15000*4000*4500

▮ Technical parameters of STLP chicken pellet mill
★ Low requirement on floor space and workshop condition;
★ Direct use by easily connecting the machines, no need for civil engineering or complex intallation like welding;
★ Continuous production with easy operation, only 1-2 operator is needed.
★ Lower invest on project site, installation fees, and labor cost.
Contact Now for Catalogs & Best Price!

▸Wide Application of ABC Machinery Poultry Feed Machine

This flat die poultry pellet mill can be used for making chicken feed pellets, goat feed pellets, cattle feed pellets, rabbit feed pellets, fish feed pellets, dog feed pellets, etc., and is specially suitable for small or medium feed factory, breed farm or aquatic base.
It has the better raw material versatility, which can be suitable for pelletizing various raw materials such as corn, broomcorn, wheat, beans, oil seed meal, boine powder and so on. Also, this manufacturing plant for animal feed has the features of low energy consumption and high production efficiency for larger profits.
Contact Now for Catalogs & Best Price!

▸Flow Chart of ABC Machinery STLP Chicken Pellet Mill

101	Grinding Machine	402	Air Lock
201	Vertical Mixing Machine	403	Pellet Cooling Machine
301	Screw Conveyor	404	Vibrating Screen
302	Temporary Storage Silo	405	Air Lock
303	Screw Feeder	406	Cyclone Dust Collector
304	Pellet Mill	407	Fan
401	Belt Conveyor	501	Electric Control Cabinet

Notes: Machines can be added, removed, or replaced according your requirements. We can customized the whole line to meet your production and budget requirements.
As shown in the above figure, the maize and soya bean meal (store & directly feed on ground) is sucked into the Grinding Machine 101 and crushed into fine powder. Any other powder/soft materials, such as wheat bran, bone meal, microelement, vitamin, etc, which don't need to be crushed, they can directly feed into the Vertical Mixing Machine 201 from its feeding port. All materials are mixed uniformly and discharged into the hopper of Screw Conveyor 301 then feed into Temporary Storage Silo 302 by screw conveyor. By Screw Feeder 303, the mixed materials are uniformly and continuously feed into the Pellet Mill 304 then produced into feed pellets. The pellets are discharged into the hopper of Belt Conveyor 401 then feed into the Pellet Cooling Machine 403 through Air Lock 402. With the cooling process, the fresh & hot pellets are cooled, the pellet temperature is not more 5 than the room temperature. The cooled pellets are screened by the Vibrating Screen 404, then they can be packaged.
Contact Now for Catalogs & Best Price!

▸Details of ABC Machinery STLP Poultry Feed Machine

▸Package and Shipment of ABC Machinery STLP Poultry Pellet Mill

Contact Now for Catalogs & Best Price!

▸Why Choose ABC Machinery?

▸Customer Feedbacks

---
