Two Chuck Lathe Pipe Thread Machine

Product Description

Q1325 CNC pipe thread lathe
Product Parameters

SPECIFICATION OF LATHE MACHINE
ITEMS		UNIT	Q1325 pipe threading Lathe
Capacity	Swing over bed	mm	800
	Swing over cross slide	mm	480
	Distance between centers	mm	3000
	Pipe threading range	mm	50-250
	Guideway width	mm	600
	Max. load capacity	T	4
Spindle	Spindle bore	mm	255
	Spindle speed steps	-	VF. 4 steps
	Spindle speed range	rpm	25-350
	Chuck	mm	φ630 4-jaw manual
Turret	Turret/tool post	-	Manual 4 position
	Tool shank size	mm	32 x 32
Carriage	X axis travel	mm	420
	Z axis travel	mm	2750
	X axis feed grade/range	mm/r	32/0.0475-0.72
	Z axis feed grade/range	mm/r	32/0.095-1.44
	Lead screw pitch	in	1/2″
	Z axis rapid traverse	mm/min	4000
	Metric thread grade/range	mm	22/1-15
	Inch thread grade/range	T.P.I	26/14-1
Tailstock	Tailstock quill diameter	mm	Φ120
	Tailstock quill taper	-	MT6
	Tailstock quill travel	mm	250
Motors	Main spindle motor	kW	15
	Rapid traverse motor	kW	1.1
	Coolant pump motor	kW	0.125
Accuracy	Turning accuracy standard	--	IT6-IT7
	Turning roundness	mm	≤0.01
	Turning cylindricity	mm	0.030/300
	Turning flatness	mm	0.025/Φ300
	Turning roughness	μm	Ra 1.6-Ra 3.2
Machine Dimension	Width x Height	mm	1700 x 1600
	Length	mm	5600
Weight	Net weight	T	7.8
Voltage			380V 50HZ

Q1325x3000mm
Configuration :
Front φ630 4-jaw manual chuck 1set; Rear φ630 4-jaw manual chuck 1set
Lighting lamp; Coolant pump; Pad iron; Anchor bolts; Taper bar device; Dead centre MT6;
Protective cover(toolpost); Tool box (Wrench etc.)
φ630 3-jaw manual chuck 2set with connect plate
pay term
Shipped per: BY SHIP
Payment Terms: 30% down payment T/T before order, and 70% TT before exfactory.
Price Terms: FOB Qingdao, china
Delivery Time:Eighty days since received down payment within a week at PI date
Warrenty period of main machines: One years, free part within one year if normal use.
Detailed Photos

---
