on-Grid Solar Wind Hybrid System with 5kw Wind Generator

Product Description

Product Description
On Grid Wind Turbine System
On Grid Wind Turbine System
The On Grid Wind Turbine System is a reliable and efficient solution for harnessing wind energy. It consists of a wind turbine, on grid controller, on grid inverter, metering device, and power distribution system.
Wind Turbine
High standard, quality components designed for harsh and extreme environments
Low wind speed model with electric brake and overcharging protection
High efficiency and low mechanical resistance energy loss
Excellent heat dissipation due to the aluminum alloy outer frame and special internal structure
High strength from fully heat-treated aluminum, anti-corrosion, and weatherproof
Generator designed with special material to resist corrosion and oxidation
Reliable and long operational lifetime under long-term full output
Designed for a 20-year operational life
Patent protected design
Product Details
Imported NSK Bearing: The generator adopts NSK bearing, ensuring normal operation at high speeds.
Pure Copper Enameled Wire: Copper wire with high-temperature resistance for efficient power generation.
NdFeB Magnet: Generator magnetic steel with high resistance to demagnetization.
Pure Copper Electric Slip Ring: Slip-ring with high copper content for long-lasting operation.
Convenient Flange Design: Humanized flange design for easy maintenance and installation.
On Grid Wind Turbine Inverter Performance Characteristics
Main circuit uses DSP chip from American TI company, German Infineon IGBT module, and Japanese Mitsubishi movement for drive protection.
SPWM pulse width modulation technology for pure sine wave output and automatic synchronous tracking with the grid.
Wind turbine input maximum power tracking technology (MPPT).
Power curve of the wind turbine can be set, with expandable points.
7-inch color touch screen display for easy system operation and parameter setting.
On grid inverter current closed-loop control for precise adjustment.
Wide input DC voltage range to adapt to different occasions.
Frequency disturbance detection technology for anti-island control.
Comprehensive power protection scheme and self-detection and protection functions.
Compact circuit structure with maximum efficiency of ≥98%.
Supports RS485, WiFi, GPRS, Ethernet, and other communication methods for real-time monitoring and historical data retrieval.
Experience the power of wind energy with the On Grid Wind Turbine System from Jinan Deming Power Equipment Co., Ltd.
Detailed Photos
Product Parameters

5KW Wind Turbine Technical Parameter
Wind turbine model	DM3.2-5.0KW
Rated power(KW)	5KW
Max power(KW)	6KW
Rated speed(r/min)	380r/min
Rated voltage(Vdc)	220Vac
Rated current(A)	16A
Start torque(n/m)	2n/m
Start-up wind speed(m/s)	2m/s
Rated wind speed(m/s)	9m/s
Safe wind speed(m/s)	35m/s
Generator style	3 phases PM generator
Generator material	Aluminium body,copper wire,Nd-Fe-B
No. of blades	3 pieces
Material of blades	Reinforced fire glass steel
Braking system	Electromagnetic braking control
Tower height(customized)	Pull rod and independent rod
5KW On Grid Wind Turbine Controller Technical Parameter
Wind turbine Rated Power	5KW
Wind turbine max power	10KW
Input voltage range	AC0-330V
Braking voltage (DC)	350V±1%
Manual control	Manual brake,*remote control brake (with communication function)
Automatic control function	Dump load control, * yaw, * pitch, * mechanical brake, * hydraulic brake, * electromagnetic brake
5KW On Grid Wind Turbine Inverter Technical Parameter
Rated output power (AC)	5KW
Max. Output power (AC)	5.5KW
Input voltage rang (DC)	0-450V
MPPT Voltage range (DC)	100V-400V
Max. Input current (DC)	16A
Rated current	17.6A
Allowable grid voltage range (AC)	110V/120V/220V/230V (Single-phase)±20%
Allowable grid frequency range	50Hz/60Hz±10%
