| Item | Unit | HBTS60-13-90 | |
| Theoretical o utput | Piston side | m3/h | 37 |
| rod side | 74 | ||
| Theoretical pressure on concrete | Piston side | MPa | 12.5 |
| rod side | 7.3 | ||
| Specification of pumpable concrete | Slump constant | mm | 80-230, Optimum 160200 |
| Aggregate size | mm | Pebble≤40,Macadam≤30 | |
| Carging hopper | Capacity | L | 500 |
| Height | mm | 1375 | |
| The mode of distributuin | "S"valve | ||
| Oil tank capacity | L | 500 | |
| Electromotor | Type | Y280M-4 | |
| Power | kW | 90 | |
| Pipe diameter | mm | φ125 | |
| Pipe cleaning mode | Compressed air or water washing | ||
| Dimensions (L*W*H) | mm | 6440*2060*2150 | |
| Weight | kg | 6300 | |
| Concrete cylinders diameterxstroke | mm | φ200*1800 | |
