Ydz20 Desktop Hydraulic Drilling Machine

US$1,700.00-1,800.00 1 SET (MOQ)

Basic Info.

Model NO.
YDZ20
Structure
Vertical Drilling Machine
Layout
Vertical
Controlling Mode
CNC
Number of Shaft
3
Hole Diameter
<50mm
Automatic Grade
Automatic
Precision
High Precision
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Outer Diameter of Stand Column
120mm
Outer Diameter of Spindle
75mm
Stroke of Spindle
140mm
Spindle Power
2HP/6p
Transport Package
Wooden
Specification
worktable size 370*400
Trademark
Yongxiong
Origin
Zhejiang, China
HS Code
8465920000
Production Capacity
5000sets/Year

Product Description

Product Description
YDZ20 Desktop Hydraulic Drilling Machine
Hydraulic drilling machine is a single column, all hydraulic radial drilling machine. is our most popular radial drilling
machines . With widely use of universal machine, suitable for in machinery manufacturing departments in the processing of small parts, drilling, reaming, reaming, countersink flat and tapping. In process equipment conditions, can also be used for boring.has been exported to all over the world ,and it is satisfied by all of the customers .
Hydraulic transmission
Hydraulic clamping
Hydraulic pre-selection
Hydraulic changs speed
Mechanical and electricity machinery double insurance
Detailed Photos
Product Parameters
Specifications
YDZ20
Max drilling dia
S45C/20mm
Spindle taper
MT2
Spindle stroke
135mm
Headstock travel(manual)
200mm
Spindle speeds
500/800/1200/1800 rpm
Feed range
0.056-1.80mm/r 9 steps
Table size
370x400mm
Table vertical travel
300mm
Max.distance spindle nose to table
670mm
Main motor power
2HP/4P
Sttandard working pressure
20kgf/cm(2mpa)
N/W
350 kg
