The SS sintered mesh filter disc

Product Details

Product Description

Product Description
The SS sintered mesh filter disc is made of multilayer (usually five layers) 316L or 304L stainless steel wire, and is sintered by high temperature vacuum, argon arc or plasma welding. Adjust the size and distribution of holes by selecting the wire diameter, mesh size and weaving method of the wire mesh. Sintered wire mesh has excellent filtration precision, filtration resistance, mechanical strength, wear resistance, heat resistance and processability.
Product specification
Material: SUS316L, SUS304L
Size: Length 500-1200mm; Diameter 20-400mm
Filtration accuracy: 1~100μm
The standard five-layer sintered mesh includes: reinforcement layer, reinforcement layer, separation layer, filter layer, protection layer
Shape: square, round, shaped (customized)
Product features
1. Economical option.
2. Uniform aperture.
3. High temperature & corrosion resistance.
4. Cleanable & reusable.
Applications
1) Used as a dispersed cooling material in high temperature environment
2) Used for gas distribution, air flotation transportation, fluidized bed, gas collection, and shock absorption, noise reduction, flame retardant
3) Used as a high-precision, high-reliability filter material
4) For high pressure backwash oil filter
What are the components of a porous metal filter?
Porous metal filters work well with all the components that make porous metal filters.
Below are some components of porous metal filters that contribute to the proper functioning of the metal filter.
Filter housing
This is the exterior of the porous metal filter and will house all components of the porous metal filter. You will rely on the porous metal filter housing to protect the internal components of the porous metal filter.
Entry and exit unit
The inlet is the unit that facilitates the introduction of the fluid to be filtered through the porous metal filter.
The outlet device will release or remove clean fluid from the porous metal filtration system.
It also has a flush outlet that you can use in the middle of flushing liquid should a situation arise.
Filter
You will rely on porous filter units to filter or stop solid particles from moving to the next stage.
It has pores of varying sizes that retain solids and prevent them from moving to the next stage.
Cleaning indicator
You'll rely on the cleaning indicator to guide you through the cleaning process.
It lights up in different colors to indicate the different cleaning stages of the porous metal filter.
Reciprocating flushing nozzle
You'll use the reciprocating flush nozzle to help reciprocate the different fluids.
This will help to alternate between different types of fluid before flushing the fluid through the flush outlet.
Package
1.The SS sintered mesh filter elements are usually packed in cartons, wrapped in soft film, fixed in the box filled with industrial foam cotton, and the outer baler is packed with plastic bags to ensure that the products have no collision, no shaking, and no damage during transportation.
2. Wooden box export packaging can also be customized. The foam cotton can be filled and fixed, the external box is sealed, the bottom is specified, and the whole packaging is processed, and the goods can be delivered to the designated place of the customer without damage.

---
