| US$30,000.00 | 1 SET (MOQ) |
| 1 | Excellent plasticating unit. |
| 2 | Bridge clamping unit for synchronism mould open/close, cycle time less. |
| 3 | Optional servo system can save 35 to 40% energy compared to normal system. |
| 4 | Optional servo rotary, precise, long using time, easy maintenance, save energy. |
| 5 | Optional injection with all-electric way, replacing hydraulic way. |
| 6 | CE certificate. |
| Item | Unit | Date | |
Injection system | Screw Diameter | mm | 35 |
| Max. Theoretical injection capacity | G | 146 | |
| Heating capacity | KW | 6.5 | |
| No. of heating area | Qty | 3 | |
| & Clamping & blowing system | Clamping force of injection | kn | 280 |
| Clamping force of blowing | kn | 30 | |
| Opening stroke of mold platen | mm | 120 | |
| Max. Platen size (L×W) | mm | 300×200 | |
| Min. Mold thickness (H) | mm | 180 | |
| Heating capacity of mould | KW | 2.0 | |
| Product dimension range | Suitable bottle range | ml | 3-500 |
| Max. bottle height | mm | ≤145 | |
| Max. Dia. of bottle | mm | ≤60 | |
| Dry cycle | s | 4 | |
Hydraulic driving system | Motor power | KW | 11/15 |
| Hydraulic pressure | Mpa | 14 | |
Pneumatic system | Min. Air pressure | Mpa | ≥0.8 |
| Discharge rate of compressed air | M3/mm | ≥0.7 | |
| Cooling system | Water flowage | M3/h | 3 |
| Total rated power with mold heating | KW | 24 | |
Machine information | Dimension | M | 3.3×1.1×2.2 |
| Machine weight | Ton | 2.5 |
