| US$120.00-138.00 | 1 Piece (MOQ) |
| Electrical Specifications | |
| FrequencyRange | 350-400/400-450/450-500/500-560 700-775/775-850/850-930/930-1020 |
| Gain(dBi) | 4-6±1dBi |
| VSWR | ≤2.0 |
| Polarization | 8*/Vertical/Horizontal |
| Horizontal Beamwidth(0º) | 75±10°/45±5°/ 32±3° |
| Vertical Beamwidth(0º) | 65±10°/35±5°/16±3° |
| Front-to-back ratio(dB) | ≥15/≥18/≥20/≥23 |
| Input Impedance(Ω) | 50Ω |
| Maximum input power(W) | 50W |
| Inpur connector type | 8*N-J with 1.5M Black RG195 Cable |
| Lightning Protection | DC Ground |
| Mechanical Specifications | |
| Dimensionsmm(Height/Width/Depth) | 820*390*50mm |
| Packing size(mm) | 830*410*180mm |
| Antenna weight(kg) | 4.5±0.3Kg |
| Operational Humidity(%) | 10-95 |
| Radome Color | Black/Navy |
| Radome material | ABS |
| Operating temperature(ºC) | -30~65° |
| Installution Method | Handheld |
