US$500.00-600.00
|
1 Piece
(MOQ)
|
Basic Info.
Light Source
LED Blue Excitation
Battery Charging Time
8hrs
Transport Package
in Cartoon
Specification
199*68*90mm
Production Capacity
500 Unit/Units Per Month
Product Description
Product Description
The Colorimeter is a professional colorimeter designed and produced subject to the relevant standards of the International Commission on Illumination (CIE) and national stands. Being with brand new imported key components, the instrument is well designed and features precision, stability, easy handling, easy to learn, and cost-effective. The instrument applies to color quality control, color difference control, color difference analysis, sampling testing, and online testing for industries such as textile, printing and dyeing, garments, shoes, leather, chemical, plastic, pigment, paint, ink, printing, metal, photography, and toys, etc., as well as to the auxiliary color matching during the processes as an injection, inking, painting and spraying coating, etc.Specification
Model | WF28 |
Display Mode | CIELAB,CIELCH |
Color Difference Formula | E*ab |
Illumination Condition | CIE Recommendation:8/d |
Light Source | LED blue excitation |
Sensor of colorimeter | Photodiode array. |
Measurement Caliber | φ8mm |
Measurement Condition | Observer: CIE 10° Standard observer Light source: D65 Contain light way:SCI SCE |
Measurement Range | L: 0 to 100 |
Repeated Accuracy | E<0.07(take the deviation average after 30 times measuring the whiteboard) |
Table Difference | E<0.2 |
Measurement Interval | 0.5 Sec. |
Storage Capacity | Type sample data : 100 with testing sample data: 200 |
Language Patterns | Simplified Chinese/English |
Battery Charging Time | 8 hrs |
Battery | Li-ion battery, 5000 times Measurement |
Lifetime of Bulb | 5 years more than 1.6 million measurements |
Display Screen | TFT true color 2.8inch@(16:9) Resolution ratio:400x240 |
Interface of External | RS-232 (115200bps)- connected with micro printer |
Working Temperature Range | 0°C-40°C(32°F-104°F) |
Storage Temperature Range | -20°C-50°C(-4°F-122°F) |
Humidity Range | Relative humidity less than 85%,without condensation |
Weight | 700g |
Size | 199*68*90mm |
Size of Exterior Package | 400*240*340mm |
Standard Accessories | 3000mAH Li-ion battery/AC adapter/User manual/Warranty card |
Optional Accessories for colorimeter | Flour measuring device/Liquid measuring device/Micro printer |
Packing and Deliver
After Sales Service
We have a professional after-sales team with global service coverage and a 24-hour time difference free to provide you with solutions.
FAQ
1. Are you a manufacturer or not?Yes, we are.We have more than 300 workers and 26680 square meters of production base in Zhejiang province which is close to Shanghai and Ningbo port. Welcome to come and visit our factory.
2. How do you guarantee the quality of your products?
We have passed ISO9001 / 14001 / 45001 quality system certification. And has a professional quality inspection team of more than 30 inspectors. Adhere to the strict quality control of each process from raw materials to packaging.
3. What is your after-sales service?
The warranty time is 1 full year, lifelong maintenance.
4. How long is your delivery lead time?
It is generally 3-5 days, but it will vary according to different products and quantities. 5. OEM available?
Yes, OEM is acceptable. Please contact us for specific information.Company Profile
TOP Cloud-agri was founded on 2008. It is a national high-tech enterprise specializing in the design, development, manufacture, and sales of agricultural testing instruments, laboratory equipment, and smart agriculture. The core products of the company are testing instruments in seed shape measurement, seed breeding, sampling, cleaning, storage, seed vigor and health research, plant physiology, soil physical properties analysis, crops quality analysis, food safety detection, agriculture produce quality testing, plant protection, pest forecast, and monitoring, weather monitoring, water quality detection, smart agriculture solutions, and other general laboratory devices.
Certificate
TOP Cloud-agri has passed ISO9001:2015,ISO14001:2015,ISO45001:2018 .Now we are speeding up the construction of Three Major Base.Up to now, TOP Cloud-agri has joined the National 863 project, State Star Plan Project, and other multiple national scientific research projects, and the company was awarded 18 national Invention patents, 40 utility model patents, 7 appearance patents, 140+ product software copyright, 39 software product registration; Meantime, TOP Cloud-agri has been identified as Zhejiang Provincial Academician Workstation, Provincial Enterprise Research Institute.Customer Response
>>
