Materials：This Automatic Temperature Controlled Oil Press Series can be used to press various raw materials, such as peanuts, rapeseeds, sesame ,soybean, cotton seeds, tea seeds, sunflower seeds, palm kernel.coconut meat ,etc. it is widely used in big-medium-small scale cooking oil factory and private user.
Advantage：Automatic Temperature Controlled Oil Press Series is an advanced spiral oil press characterized by its high oil output rate with good quality, simple design, easy to use and continuous operation.
The auto-heating function of the press has replaced the traditional way by squeezing residue cake, which could shorten the preparation work, reduce the energy consumption and abrasion, and thus lengthen the durability. When the squeezing is suspended,the temperature can be maintained by this system.
Model
| YZYX90WK
| YZYX10WK
| YZYX10-8WK
| YZYX120WK
| YZYX130WK
| YZYX140WK
|
Capacity
(t/24h)
| ≥3
| ≥3.5
| ≥4.5
| ≥6.5
| 8-10
| 9-11
|
Oil Content
of Dry Cakes(%)
|
≤7.8
|
≤7.8
|
≤7.8
|
≤7.6
|
≤7.6
|
≤7.6
|
Motor Power(kw)
| 5.5
| 7.5
| 11
| 15
| 18.2
| 22
|
Dimension(mm)
| 1200*550*1000
| 1620*580*1165
| 1720*580*1165
| 1860*622*1275
| 1950*742*1500
| 2010*690*1430
|
Weight(kg)
| 300
| 570
| 590
| 700
| 900
| 830
|
Temperature Control
Power(kw)
|
2.4
|
2.65
|
2.65
|
3.6
|
3.6
|
3.6
|
500KG palm oil press machine
Edible oil refining machine
Palm kernel press machine
Company Profile
Successful Cases
Certifications
Product packaging
FAQ
Q: Why always choose Doing?
A: More than 40 years’ manufacturing experience;26 technical engineers research on new efficient processing craft and instruct manufacturing and installation work;76 technicians in our professional installation team with rich and mature installation and training experience;CE & ISO9001&BV&TUV certificate.
Q: What's your factory's ability, which kind of machine do you manufacture? A: We can produce all kinds of edible oil machinery, which includes palm oil production machine, peanut oil, soybean oil, cotton oil,sunflower oil, corn oil, rice bran oil and other kinds of edible oil.
The whole line includes oil press line, oil extraction (solvent) line, oil refinery line, palm oil fractionation line, sunflower oil dewaxing line, decoloring process, deodorization process and others.We can produce biodiesel plant/equipment/machines also. On the other hand, our factory developed ourselves, import many advanced technology to strengthen ourselves and ensure our customer's right.
Q:What is your guarantee time?
A:At least one year with all necessary after-sale service provided.
>>
