40 42 48 60 Inch Woodworking Vertical Bandsaw Log Cutting Machine

Product Description

Product Parameters
Manual Feeding Band Saw

Model	WS32	WS36
Saw Wheel Diameter MM	800	900
Saw Wheel Width MM	110	120
Blade Length MM	5700	6400
Main Motor Power KW	15	18.5
Saw Wheel & Clip Up/Down	Manual	Manual
Main Motor,Iron Made Safe Protective casing,Manual Lubrication

Auto Feeding Vertical Band Saw

Saw Wheel Diameter *Width	800*110MM
Max Sawing Width*Height	200*400MM
Casted Working Table Size	1000*1000MM
Main Motor Power KW	15KW
Feeding Motor	2.2KW
Saw Wheel & Clip Up/Down	0.75KW
Feeding speed	10-40 Meters/Minute
Weight KG	2000KG
Main Motor,Iron Made Safe Protective casing,Manual Lubrication

Band Saw With Turning Table

Saw Wheel Diameter	650mm
Saw Blade Width	75mm
Motor Power	7.5kw
Weight	750kg

Single Vertical Saw

Max Sawing Width	400MM
Max Sawing Height	300MM
Saw Wheel Diameter	700MM
Feeding Chain Conveyor	15 Meters *150MM
Motor Power	15KW
Feeding Speed	5-20 Meters/Min
Feeding Conveyor Motor	2.2KW
In + Out Feeding Chain Conveyor	2000MM+2000MM
Weight	1200KG

Twin Vertical Band Saw

Model	WS350	WS500	WS400
Sawing Wood Width MM	100-350	300-500	100-400
Sawing Wood Length	1000-3000	1000-3000	1000-3000
Saw Wheel Diameter	700MM	760MM	700MM
Feeding Speed	9-25 M/Min	9-25 M/Min	9-25 M/Min
Conveyor Length	3500MM*2	3500MM*2	7000MM
Saw Motor	2*18.5KW	2*22KW	2*18.5KW
Feeding Motor	5.5KW	4KW*2	5.5KW
Saw Blade Width*Thickness	80*0.9MM	100*1.05MM	80*0.9MM
Touch Screen Setting Sawing Size And Digital Display Variable Frequency Speed Adjustable Feeding Speed

Related Machines
WS36 Vertical Band Sawmill With
Manual/Electric/CNC/Pneumatic/Hydraulic Log Carriage

Wheel Diameter (MM)	900
Max Sawing Diameter	700
Saw Blade (MM)	6400*125*1.05
Main Motor Power( KW)	18.5
Log Carriage	Manual	Electric	Manual	Electric
Carriage Length MM	3000		5000
Max Sawing Length MM	4000		6000
Clamping	Manual *3		Manual*4
Walking	Manual	Electric	Manual	Electric
Sizing	Manual	Electric	Manual	Electric

Options	Specification
CNC Log Carriage	Touch Screen Sizing,Electric Clamping,VFD Walking
Pneumatic Log Carriage	Pneumatic Clamping,Pneumatic rotation,touch screen sizing,VFD walking
Hydraulic Log Carriage	hydraulic Clamping,Hydraulic rotation,touch screen sizing,vfd walking
Log Loading Deck	5000*2000MM,5000*4000MM
Roller Conveyor	5000*800MM,8000*800MM
Chain Conveyor	1800*200MM,4000*2000MM

WS40 Vertical Wood Band Sawmill With Electric/CNC/Pneumatic/Hydraulic Log Carriage

Saw Wheel Diameter	1000(MM)
Max Sawing Diameter	800(MM)
Saw Blade	6850*125*1.05(MM)
Saw Clip & Wheel Up & Down	Electric
Main Motor Power( KW)	22
Log Carriage	Electric		CNC	Electric	CNC
Carriage Length	3000MM			5000MM
Max Sawing Wood Length	4000 MM			6000MM
Clamping	Manual*3	Electric*3		Manual*4	Electric*4
Walking	Electric	VFD		Electric	VFD
Sizing	Electric	Touch Screen		Electric	Touch Screen

WS42 Vertical Wood Band Sawmill With Electric/CNC/Pneumatic/Hydraulic Log Carriage

Saw Wheel Diameter	1070
Max Sawing Diameter	1000
Saw Blade	7400*150*1.05
Saw Clip & Wheel Up & Down	Electric
Main Motor Power( KW)	30
Log Carriage	Electric		CNC	Electric	CNC
Carriage Length	3000MM			5000MM
Max Sawing Wood Length	4000 MM			6000MM
Clamping	Manual*3	Electric*3		Manual*4	Electric*4
Walking	Electric	VFD		Electric	VFD
Sizing	Electric	Touch Screen		Electric	Touch Screen

WS48 Vertical Wood Band Sawmill With Electric/CNC/Pneumatic/Hydraulic Log Carriage

Saw Wheel Diameter	1250MM
Max Sawing Diameter	1200MM
Saw Blade	8600*150
Saw Clip & Wheel Up & Down	Electric
Main Motor Power( KW)	37KW
CNC Log Carriage	3000MM	5000MM
Max Sawing Wood Length	4000MM	6000MM
Clamping	Electric*3	Electric*4
Walking	Frequency	Frequency
Sizing	Touch Screen	Touch Screen

WS60 Vertical Wood Band Sawmill With Electric/CNC/Pneumatic/Hydraulic Log Carriage

Saw Wheel Diameter	1250MM
Max Sawing Diameter	1500MM
Saw Blade	9200*150
Saw Clip & Wheel Up & Down	Electric
Main Motor Power( KW)	45KW
CNC Log Carriage	3000MM	5000MM
Max Sawing Wood Length	4000MM	6000MM
Clamping	Electric*3	Electric*4
Walking	Frequency	Frequency
Sizing	Touch Screen	Touch Screen

Company Profile
Specialize in research & development, production, sales of sawmills and the relevant fittings SINCE 1988
We have serves 11,000 enterprises and our products have been exported to over 60 countries in the world.
Our Band Sawmill machines including:
Hydraulic Heavy Duty Horizontal Sawmill
Hydraulic Portable Horizontal Sawmill
Multiple Heads Horizontal Resaw Band Saws
Heavy Duty Horizontal Sawmill
Portable Horizontal Sawmill
Thin Cutting Horizontal Resaw
Mini Portable Sawmill
Twin Vertical Band Sawmill
Vertical Band Sawmill
Log Carriage (Manual,Electric,Pneumatic,Hydraulic)
Band Saw Blade
Band Saw Blade (Sharpener,Butt Welder,Roller)
Brazing Machine (Manual/Automatic Stellite/Tungsten)
Blade Grinding Machine(Manual/Automatic ,Side/Angle)

Sawmill & Kilns & Pallet & Biomass & Forestry & Recycling
Sincerely welcome worldwide distributors to join us!

---
