| Gasoline Generator Data |
| Set Type | XGGF3500E |
| Rated Frequency | HZ | 50 |
| Rated Output Power | KVA | 2.8 |
| Maximum Output Power | KVA | 3.2 |
| Rated Voltage | V | 230 |
| Rated Current | A | 12.2 |
| Rated Speed | r/min | 3000 |
| Generator | Generator Type |
| KT-3 |
| Pole Number |
| 2 |
| Phase Number |
| Single |
| Excitation Mode |
| Self Excitation |
| Power Factor | COSΦ | 1.0 |
| Insulation Class |
| B |
| Engine | Type |
| XG178FG |
| Cylinder Type |
| One Cylinder,4 stroke,Air cooled,Direct Injection |
| Bore×Stroke | mm | 78×62 |
| Gross Displacement | ml | 296 |
| Compression Ratio |
| 20∶1 |
| Rated Power | KW | 3.68 |
| Lubrication method |
| Pressure Spray |
| Lubrication Type |
| CD30 |
| Lubrication Capacity | L | 1.1 |
| Starting method |
| Recoil hand starting or Electrical Starting |
| Star Motor Capacity | V-KW | 12V 0.8KW |
| Charge Alternator Capacity | V-A | 12V 3A |
| Accumulator Capacity×Number | V-Ah | 12V 36Ah |
| Fuel Type |
| Gas |
| Fuel Consumption Rate | g/KW.h | ≤370 |
| Set | Panel Style |
| Common |
| Output | Voltage | V | 115/230 |
| Socket |
| Two Singe Phase Socket |
| Binding post |
| No |
| DC12V Output |
| Binding Post Output |
| Noise（7m） | dB(A) | 77 |
| Structural style |
| Open |
| Fuel capacity | L | 13.5 |
| Continuous Running Time | h | 8.5 |
| Overall Size | mm | 655×480×530 |
| Net Weight | kg | X：65 E:70 |
| Packing | Packing Material |
| Carton |
| Carton Size | mm | 695×520×575 |
