Weix Chuck Nut Er11 Er16 Er20 Er25 Er32 CNC Milling Engraver Nut Spring Collection Nut Clamp

Product Description

Product Description
machine tools accessories er collet spring collet nut cap nut for milling tool holder
Product Description 1.material:40Cr/20CrMnTi

2.hardness:HRC44-48/52-60

3.Type:A/B/M/TI/T2

4.Balance nuts also available.

5. Hardened & Precision Ground

What we sale the similar products?DIN6499B er collet precision 0.015,er collet high precision 0.008,
ERC cool collets,ERG tapping collet ,er collet milling chuck set ,
EOC collet,R8 collet ,5C collets,DIN6343 clamping collets,Tapping collets,
TG75TG100 collets,SK collets ,SDC collet

UM/T2
Model	D(mm)	d1(mm)	L(mm)	T	Wt(kg)
ER16-UM	32	26	17	M22X1.5	0.05
ER20-UM	35	29	19	M25X1.5	0.1
ER25-UM	42	36	20	M32X1.5	0.14
ER32-UM	50	44	22.5	M40X1.5	0.2
ER40-UM	63	57	25.5	M50X1.5	0.3
ER50-UM	78	71	35.5	M64X2	0.5
A/Hex
Model	D(mm)	d1(mm)	L(mm)	T	Wt(kg)
ER11-A	19	17	11.3	M14X0.75	0.005
ER16-A	28	25	17.5	M22X1.5	0.01
ER20-A	34	30	19	M25X1.5	0.05
Mini
Model	D(mm)	d1(mm)	L(mm)	T	Wt(kg)
ER8-M	12	10	10	M10X0.75	0.005
ER11-M	16	12	12	M13X0.75	0.01
ER16-M	22	17.2	18	M19X1	0.05
ER20-M	28	22.5	19	M24X1	0.05
ER25-M	35	28.6	20	M30X1	0.08

Packing & De livery

UM/T2
Model	D(mm)	d1(mm)	L(mm)	T	Wt(kg)
ER16-UM	32	26	17	M22X1.5	0.05
ER20-UM	35	29	19	M25X1.5	0.1
ER25-UM	42	36	20	M32X1.5	0.14
ER32-UM	50	44	22.5	M40X1.5	0.2
ER40-UM	63	57	25.5	M50X1.5	0.3
ER50-UM	78	71	35.5	M64X2	0.5
A/Hex
Model	D(mm)	d1(mm)	L(mm)	T	Wt(kg)
ER11-A	19	17	11.3	M14X0.75	0.005
ER16-A	28	25	17.5	M22X1.5	0.01
ER20-A	34	30	19	M25X1.5	0.05
Mini
Model	D(mm)	d1(mm)	L(mm)	T	Wt(kg)
ER8-M	12	10	10	M10X0.75	0.005
ER11-M	16	12	12	M13X0.75	0.01
ER16-M	22	17.2	18	M19X1	0.05
ER20-M	28	22.5	19	M24X1	0.05
ER25-M	35	28.6	20	M30X1	0.08

We have our own factory. We have 42 workers and 3inspectors.
Our old engineers have about 12years experience in these area.We established an independent commercial company in 2012.
We have 12 sales. Our products have been approved by many countries including German, Turkey,
Brazil,Italy, England, American, India and so on.
Main Products
FAQ

1.What's your delivery time? If a case of stock, generally within two or three days for delivery arrangement.Others require custom need 5-20 days. 2.Do you have MOQ? Yes, we do. Our MOQ is 10 pcs. Set product's MOQ is 5 sets. 3.What's your payment way? T/T, L/C, Paypal, Western Union. Keeping safe . 4.Could you undertake customized? Yes, we could. But we need your supply drawings or samples. 5.Where do you export? Our products are mainly exported to United States, Italy, Germany, Britain, Spain, South Asia and other countries.6.Are you factory or Trade Company? We are one of the trade and Industry. 7.How to control the quality of your product? Our products meet the standard of ISO9001, We have our own perfect testing equipment and sophisticated detection personnel. 8.What's your package? Plastic bag+ packing box. Set product have special kit box. 9.Can you provide a sample? Yes, we can. 10.How about the quality of your products? Our company carries our "the quality first, the goods faith for this purpose", reply on advanced productions technology and equipment, follow the scientific management concept, and strive to provide qualified perfect products for client.

---
