| US$58,000.00 | 1 Piece (MOQ) |
| LUHAO Chemical Machinery Co. Ltd | |||||
| Pressure Vessel Design Information Collection Table | |||||
| Vessel | Jacket (Coil) | ||||
| Work Medium | Name | ||||
| Components | |||||
| Density (Kg/m³) | |||||
| Characteristics | |||||
| Viscosity (cP) | |||||
| Flow Velocity(m³/h) | |||||
| Design pressure (Mpa) | |||||
| Work pressure (Mpa) | |||||
| Design temperature(ºC) | |||||
| Work temperature (ºC) | |||||
| Wall temperature (ºC) | |||||
| Diamter (mm) | |||||
| Length (mm) | |||||
| Capacity(m³) | |||||
| Effective capacity (m³) | |||||
| Corrosion allowance (mm) | |||||
| Corrosion speed (mm/year) | |||||
| Recommended Materials | |||||
| Lowest value of average monthly temperature(ºC) | |||||
| Site location | |||||
| Installation condition | Indoor or Outdoor | ||||
| Catalyst Volume(m³) | |||||
| Catalyst Density(Kg/m³) | |||||
| Heat Transfer Area(m2) | |||||
| Coil Specification | |||||
| Basic Wind Pressure(Mpa) | |||||
| Seismic Basic Intensity | |||||
| Ambient Temperature(ºC) | |||||
| Site Type | |||||
| Operating Mode | |||||
| Insulation Materials | Name | ||||
| Thickness | |||||
| Density (Kg/m³) | |||||
| Seal Requirements | |||||
| Liquid Level Gauge | |||||
| Emergency Cut-off | |||||
| Static Electricity Removal | |||||
| Anti Eddy Current Requirement for Liquid Outlet | |||||
| Installation and Mantainance Requirements | |||||
| Expected Useful Life (years) | |||||
| Safety accessories | Vessel | Jacket (Coil) | |||
| Location | |||||
| Type | |||||
| Specification | |||||
| Quantity | |||||
| Set pressure(Mpa) | |||||
| Burst disc | |||||
| Burst pressure(Mpa) | |||||
| Safety discharge(kg/h) | |||||
| Agitator | Type | ||||
| Impeller Diameter(mm) | |||||
| Speed(r/min) | |||||
| Motor | Model | ||||
| Power(kw) | |||||
| Explosion Proof Grade | |||||
| Speed reducer | |||||
