2m Asphalt Cold Milling Machine Sm200m-3

Product Description

2M Asphalt Cold Milling Machine SM200M-3
Product Description
Drive system
♦ SD-EC electronically controlled engine conforms to the China-III non-road machinery emission regulation, featuring high intelligence and efficiency, high parts universality, and low maintenance cost.
♦ The energy-saving technologies, including automatic idling of engine, are utilized to realize better fuel economy, low emission load, and high working efficiency for the whole machine.
♦ The hydraulically-driven milling drum features simple structure and high reliability.
Milling rotor assembly
♦ The new milling rotor is equipped with highly wear-resistant quick change cutter holder to realize high operating capability, with the milling depth up to 200mm.
♦ A powerful sprinkling system is installed at the milling rotor.
♦ The side plates on two sides are hydraulically lifted.
♦ The optional economic and finish milling drums are offered to meet diversified operation requirements.

Traveling system
♦ The traveling system adopts full-hydraulic four-wheel drive to achieve powerful gradeability and drive onto and from the flat-bed transport vehicle by self-propelling more safely.
♦ The working pressure of traveling system is >375bar, featuring powerful traction capability.
♦ The traveling system incorporates the forced distribution function to effectively prevent slip.
♦ The traveling speed is up to 8km/h.
♦ The right rear column is capable of 180º rotation for curb operations.
Easy maintenances
♦ The structural parts inherit the excellent quality of Shantui's mature products.
♦ The large opening design for engine hood and side doors provides a spacious room for maintenances.
♦ The core electric and hydraulic parts adopt imported products, featuring stable and reliable quality and extremely high reliability.
♦ The external fuel/oil filter and grease nozzles are installed in hanging manner to ease the maintenances and replacement.
High intelligence
♦ The CAN bus digital network control mode is applied to effectively guarantee the automatic control and protection for all motions of the machine.
♦ The installed human-machine interfaces can centrally display the digital working parameters of the machine.
♦ The malfunction self-diagnostic information and the warning and prompt information realize safer and more efficient operations of the machine.
Product Parameters

Parameter name	SM200M-3 (Standard version)
Performance parameters
Operating weight (Kg)	32000
Transport weight(Kg)	29700
Maximum milling width (mm)	2000
Maximum milling depth (mm)	320
Engine
Engine model	QSX15
Rated power/rated speed (kW/rpm)	447/2100
Overall dimensions
Overall dimensions of machine (mm)	14940*2515*4090
Driving performance
Traveling speed (km/h)	0-5
Working speed (m/min)	0-83
Conveyor System
Width of conveyor belt (mm)	800
Swing angle of conveyer (Rightward/leftward) (°)	±45
Tank capacity
Fuel tank (L)	1120
Working device
Number of milling cutters (Piece)	162
