Product Description
Product Description
XE690DK is equipped with a reinforced large undercarrage and high-power travel reducers for mine operation. Ultra long warranty period, greatly reducing the whole life maintenance cost of the excavator. A variety of attachments are provided to match the requirements of different working conditions.
Product Parameters
| SPECIFICATION OF XE690DK 65T CRAWLER CRANE |
| Item | Unit | Parameter Value |
| Model | - | XE690DK |
| | | |
| Operation Performance Parameter | | |
| Operating weight | kg | 65800 |
| Bucket capacity | m³ | 3.8-4.5 |
| Bucket digging force | kN | 382 |
| Arm digging force | kN | 318 |
| Max. digging height | mm | 10379 |
| Max. digging reach | mm | 7287 |
| Max. digging depth | mm | 6893 |
| | | |
| Engine Parameter | | |
| Model | - | WEICHAI |
| Rated power/speed | kw/rpm | 566/2100 |
| Maximum torque/speed | N.m | 3000/1500 |
| Displacement | L | 16.72 |
| | | |
| Dimension Parameter | | |
| Crane Full Dimension(L×W×H) | mm | 11388*3390*3570 |
| Width of Crawler | mm | 3030 |
| | | |
| Speed Parameter | | |
| Travel speed(H/L) | km/h | 4.9/2.9 |
| Swing speed | r/min | 7.3 |
| Gradeability | ° | 35 |
Detailed Photos
Company Profile
HOKA VEHICLE is located in Shanghai, which is a financial, trade and shipping center in China. All these give our company an obvious superiority in trade, transportation and material flow.
With the professional team, first class design, production experience and market capacity, HOKA VEHICLE has exported and delivered more than 5, 000 units Construction Machinery to countries across Africa Middle East, Southeast Asia and South America.Our main products cover more than 11 series, ranging from Hoisting Machinery, Building Machinery, Earthmoving Machinery, Concrete Machinery,Road Machinery,Logistics Machinery, Trucks, Drilling Machinery, Mining Machinery and all other kinds of Construction Machinery.
Our Factory
Our Parts Warehouse
Our Products
Our Successful Cases
>>
