Our company has been established for 26 years since 1999.Covering an area of 15,000 square meters. We have rich experience in producing and manufacturing various types of injection molding machines. Meanwhile, our machines have been successfully sold to many countries around the world, so we have extensive experience in overseas sales and after-sales service.
| Brand Name | TianCheng | | Style | VERTICAL |
| Condition | New | | Model NO. | TC-550-P |
| Screw Diameter (MM) | 30--36 | | Max.Hydraulic Pressure(Kg/cm3) | 140 |
| Maximum injection Pressure (Kg/cm2) | 2177--1513 | | Pump Output (L/min) | 57 |
| Theoretical Shot Volume (Cm3) | 98--142 | | Oil Tank Capacity (L) | 166 |
| Maximum Shot Weight (G/oz) | 87/3.0--160/5.6 | | Cooling Water Consumption(L/H) | 600-800 |
| Injection Rate (Cm3/sec) | 68--97 | | Electric Power (KW) | 7.5 |
| Screw Speed (R/Min) | 0--210 | | Total capacitance (KW) | 2.8 |
| Screw Rate (MM) | 140 | | Total Wattage (KW) | / |
| Nozzle Retraction Stroke (MM) | 220 | | Machine Specification(M) | 1.8*1.2*2.6 |
| Clamping Force (Ton) | 55 | | Weight of Machine (KG) | 2500 |
| Opening Force (Ton) | 7.2 | | Plastic Processed | PP, ABS, FRPP/PVC, PE, ABS/PP, PE/PP |
| Platen Size (MM) | / | | After-sales Service Provided
| Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support |
| Distance Between Tie-Bere (MM) | 180/240 | | After Warranty Service
| Video technical support, Online support, Spare parts, Field maintenance and repair service |
| minimum Mold Thickness (MM) | 180/240 | | Warranty | 1 year |
| Opening Stroke (MM) | 200 | | Applicable Industries | Manufacturing Plant, Construction works , Energy & Mining, Other |
| Max-Distance opening mold (MM) | 380/440 | | | |
| Max.Mold Size | 450*400 | | | |
| Ejector Force (Ton) | 1.3 | | | |
| Ejector Stoke (MM) | / | | | |
| Q1: Are you a trading company or a manufacturer? |
| A1: Factory we are, all the machine are made by ourselves. Besides, you can get the customize service with your requirements |
| Q2: What's your warranty for the machine? |
| A2: One Year Warranty(all the machine parts can be replaced within one year free of charge, not including the manmade broke), life-time maintenance. |
| Q3: What's your Delivery Time? |
| A3: Usually it is 3-5 days if the machine is in stock; If not, the delivery time is 10-25 days according to your required quantity and our busy season. |
| Q4: Why choose TianCheng Machinery Co., Ltd.? |
| A4: "Tiancheng Machinery, we sincere, you succeed!" are the driving force for our company to moving forwards. We will devote every efforts to do the best level machine and service. |
