China Made Top Wire Former Supplier for Paper Machinery

Product Description

Integra-Top Former
Products Description: Improve paper formation. Cantilever design for quick and easy wire change. Dewatering from both sides of wet sheet to improve dewatering ability. Reduce the twosideness of paper sheet and also reduce paper picking. For machine speed: 801300m/min, for trim width: up to 6600mm.
Top Former I Structure Drawing:
1. Lead-in roll
2. Curved water box
3. Front inverted vacuum box
4. Centre roll
5. Tail inverted vacuum box
6. Curved vacuum box
7. Tail roll
Top Former II Structure Drawing:
1. Lead-in roll 2. Lead-in vacuum box
3. Curved inverted vacuum box
4. Counter loading blades
5. Tail vacuum box
6. Tail roll

Different Top Formers Compare:

	Fourdrinier	Integra-top former II	Integra-top former I
Dewatering ability	Limited	High (import concentration 1.0%)	Middle (import concentration 1.5%)
Fiber retention	Basis of comparison	Minus 10%	Minus 5%
Sheet formation	Relatively poor	Good	Best
Grammage range	Low to high	Low to high	Low to medium

About Us:
Greatland Machinery is set up in 2010. The main business is to innovate and renew the old paper machine on the basis of introducing advanced foreign technology.
We has a professional technician team that devoted to paper-making industry and had reformed more than 100 sets production line successfully. We are able to make the best proposal after completely analyzing and figuring our problems of the paper production line though paper-making progress, equipment, electric automatization and so forth.
We follow the "short process" concept in implementing the customer's projects to reduce energy and water consumption. On the premise of quality assured, running speed of paper machine are made in the best condition and manufacture cost decreased on the bottom.
Value Proposition:
Greatland Machinery product value positioning is different from the traditional papermaking equipment enterprise, in addition to providing self-critical equipment and more importantly, to provide technical services, including engineering, systems integration and equipment upgrade service.
F&Q:
Q.:Are you a factory or trading company?
A.:We are a factory and manufacturer.
Q.:How does your factory do regarding quality control?
A.:We pay much attention on quality controlling from very beginning to the very end.Fully check and test takes before shipment.
Q.:Where is your factory located?How can I visit there?
A.:Our factory located at Shandong, China.You can fly to QINGDAO international airport directly.We will arrange to pick you up.
Q.:What's service or guarantee can you offer?
A.:One year guarantee for key parts of machine, Machine installing and worker training service, free technical support whole life.

---
