CNC Vertical Drilling Machine ZK5140 ZK5150

Product Description

Hoton Machinery CNC Drilling Machine ZK5140 and ZK5150
1. Zk5140B and Zk5140B-1 vertical cnc drilling machine are universal drilling machine.the max drilling diameter is 40mm.
2.Zk5150B and Zk5150B-1 vertical cnc drilling machine are universal drilling machine.the max drilling diameter is 50mm.
3. The table of Zk5140B, Z5150B is fixed and The Zk5140B-1, Zk5150B-1 is cross table.
4. This machine also can enlarge hole,drill deep hole,tapping,boring and etc. except drilling hole.
5. This series machine have many advantages,such as high efficiency, good rigid,high precision,low noise, wide speed range..the machine which have cross table ,the table can manual feeding on cross ,longitudinal and lifting.

Specification	Unit	ZK5140	ZK5150
Table size	mm	1000X545
Area of worktable	mm	850X400
Max drilling diameter	mm	φ40	φ50
T-slot width/quantity	mm	18/3	18/3
Spindle hole taper		MT #4	MT #5
Spindle speeds	r/min	31.5-1400/12 steps
Power of spindle motor	kw	3
Vertical travel of drilling head (manual)	mm	360
Travel(X/Y/Z)	mm	850/400/240
Distance from spindle nose to worktable	mm	100-700	65-665
Distance from spindle center line to column	mm	335
Rapid travel rate X/Y/Z	m/min	15/15/3.5
CNC system		KND system
Max torque of spindle	N.m	350
Max feed resistance	N	10000	12000
Positioning accuracy	mm	±0.025
Repositioning accuracy	mm	±0.015

Company Profile:

Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008.

The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale.

Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills.

---
