Mining Machine Automatic Fire Suppression Systems for Underground Mining Equipment Fire Extinguisher

Product Description

Mining Machine Automatic Fire Suppression Systems
Complexity, danger and physical aspects of engine fire
As we all know, the need to reduce emissions is increasing
As tier 4f and EPA 2013, higher fuel pressure has been caused
The temperature in the engine compartment increases. Combination With time-consuming industry demand, the risk of fire begins
The engine compartment rose sharply.
Statistics show that nearly 55% of mine fires originate from vehicle fires. this It has been a problem for many years. Among them, the hot surface is the main Causes, and several fires caused by overheating. The two are together
Causes of fire in more than 50% of vehicles
Mining operations are sensitive to unplanned downtime.
It can be devastating to have an engine on or under the ground
Minute count of operations. Due to the large amount of diesel and hydraulic oil, it usually flows under high pressure in the adjacent area
Igniting an engine fire can lead to a series of rapid and catastrophic events.
If this happens, it will eventually lead to the tragedy of vehicle damage and human death.
For example, all machine drivers have the possibility of leaking fuel pipes or broken hydraulic hoses,
Description of Mining Machine Fire Systems
1).Product Features.
Completely Automatically
Heated start, no electricity;
Simple Installation and maintenance
Suitable for Heavy duty Mining Machine
2).Specification.
NAME:TMG-SAFETY Mining Machine Fire Systems
Models:L, 9L, 12L, 20L, 25L, 50L,Equipment selection according to engine displacement
Agent:3% AFFF Foam / FM200 / Dry Powder

Working Pressure	14Bar
Testing Pressure	27Bar
Cylinder Material	St12 red painting
Certificate	CE
System Activated Temperature	140ºC

For Vehicle Engine Room, we can choose different system, AFFF3% Foam system, or FM200 System, or Dry Powder System. The different systems are with different discharge tube and nozzles.
3).Product Activated Principle.
Step1: Detection Tube ruptures to hole when temperature reach 140ºC, and Release pressure through the hole.(Or pushing the manual button of detection tube,pressure releasing from themanual button.)
Step2:The resulting drop in pressure causes the head valve to be activated. At the same time the fire arlar was activated.
Step3:Valve was opened and agent was discharged through the discharge tubing to the nozzles.
Step4:Agent covering the area and suppressing the fire quickly and thoroughly. This system is totally automatic and is totally independent of electricity.
Product Certificates:
Package and shipment:
Most of our products are with approval of CE, EN3, EN671, UL, LPCB, MED, etc.
We produce high quality fire-fighting products, and we supply one-stop purchasing service too. Our Main Product: Vehicle Fire Suppression System, Kitchen Fire Suppression System, Electric Equipment Fire Suppression System, CAFS (Compressed Air Foam System), dry Powder fire extinguisher, CO2 fire extinguisher, foam Fire Extinguisher, wet Chemical fire extinguisher, water fire extinguisher, fire hose reel, fire hydrant, fire cabinet, Fire Alarm, etc.

---
