Product Details
Product Description
Product Description
XLS 10 deep groove ball bearings
XLJ 10 imperial ball bearings
Manufacturer part number: XLS10
Dimension of 254 x 336.55 x 41.275 mm
d 254mm bore diameter
D 336.55mm outer diameter
T 41.275mm Height
Mass- 9.89 Kg
Dimension of 10X13.25X1.625 inch
d 10 inch bore diameter
D 13.25 inch outer diameter
T 1.625 inch Height
Lubrication Speed - 750 r/min Grease
Lubrication Speed - 1500 r/min Oil
Basic dynamic load rating - 130 kN Cr
Basic static load rating - 157 kN Cor
Clearance : C2(2-45), C3(90-170), C4(155-245), C5(225-340)
Rings material: Bearings steel Chrome steel
Cage: Machined brass cage M
Rolling elements: Precision balls
WKKZ bearing -ball bearings application for automotive,electric power,instrument,construction equipment,railway,agricultural machine
WKKZ bearing delivery days:
Stock bearings within 3 days
Future goods under 45 days
Urgent order within 20-25 days
WKKZ bearing quality assurance
Quality control certificates provided
Bearing material certificates provided
Sample for testing always
unconditional return within 7 days
WKKZ bearing packing for ball bearings:
1.Carton (up to 150mm inner diameter )
2.be oiled and single wrapped with water-proof belt (above 150mm inner diameter)
3.Wooden pallets or wooden case of free fumigation
4.according to customers requirement
WKKZ BEARING shipping:
Port of Loading: Dalian,Shanghai,Ningbo,Guangzhou
Air shipment,sea shipment,railway shipment,express delivery
WKKZ BEARING other ball bearings series:
DEEP GROOVE BALL BEARING
| INCH DEEP GROOVE BALL BEARING
| MJ,LJ,XLJ SERIES |
METRIC DEEP GROOVE BALL BEARING
| 6000 6200 6300 6400 6800 6900 16000 SERIES |
>>
