US$1,500.00-2,300.00
|
1 Set
(MOQ)
|
Basic Info.
Controlling Mode
Hydraulic Semi-automatic
After-sales Service
24hours Services
Applications
Cupboard,Furniture,Door,Wood Panel ,Fixtures,etc
Max.Cutting Length
3200mm
Max.Cutting Thickness
75mm
Tilting Angle
90-45 Degree
Scoring Saw Blade Diameter
120mm
Speed of Saw Blade
4500-6000rpm
Speed of Scoring Saw Blade
6000-8000rpm
Spindle of Scoring Saw Diameter
20mm
Voltage
380/220/415/440V 3phase /1phase
Transport Package
Woodcase Packing or Film Packing
Specification
3200*1100*1100 and 3250*400*300
Production Capacity
2000sets/Years
Product Description
Detailed Photos
Product Parameters
| Dimensions slidingtable | 3200*375mm |
| Maximumcuttingpanel length | 3200mm |
| Maximum cutting panel thickness | 75mm |
| Tilting angle sawblade | 0-45°mm |
| Sawblade diameter | Ø300mm |
| Scoring saw blade diameter | Ø120mm |
| Speed of main sawblade | 4500/6000rpm |
| Speed of scoring sawblade | 6000/8000rpm |
| Spindlediameter | Ø30mm |
| Spindle ofscorina sawdiameter | Ø20mm |
| Main motor power | 5.5Kw |
| Scoringpower | 1.1Kw |
| Weight | 750kg |
| Voltage | 380v/50hz 3phase/220V/415V/440V |
| Bodypackingsize | 2150*1100*1100mm |
| Tablepackingsize | 3250*400*300mm |
Workshop
Packaging & Shipping
Meeting
Feedback
Certifications
FAQ
Q1: What is the brand name of the Machine?
A1: The brand name of the Woodworking Machine is Zhongchi Brand
Q2: Where is the Woodworking Machine manufactured?
A2: The Woodworking Machine is manufactured in Qingdao,China.
Q3: Is the Woodworking Machine certified?
A3: Yes, Have CE certification.
Q4:I am a fresh man for this machine,what kind of machine I should choose?
A4:Very easy to choose, just tell us :
1. the work you want to do ?
2. the maximum size of your material ?
then we give you perfect solutions and suggestions.
Q5:When I got this machine, but I did not know how to use it,What should I do?
A5:We will send tutorial video and English version manual with the machine, If you still have some doubts,we can talk by telephone or Video. Or even send our engineers oversea to help you.
Q6:If some problems happened to this machine during warranty period,what should I do?
A6:We will supply free parts in machine warranty period if machine have some problem, While we also supply free after-service,so any doubts, just let us know, we will give you solutions.
Q7:What is the MOQ?
A7:MOQ for our products is 1 set machine, we could send it to the nearest port to you.
>>
