Expanded Graphite Sheet with Perforated Stainless Steel

Product Description

Company Profile

Product Description Stability And Reflectivity Graphite Sheet Description:
Tenglong reinforced graphite sheet is an excellent sealing material for high temperature, high-pressure transfer of liquids, gases, steam, chemicals and corrosives. It is manufactured from high purity, highcrystalline natural graphite flakes, which are processed into continuous foil by a special acid and thermal treatment to produce expanded graphite crystals.

Stability And Reflectivity Graphite Sheet Specification:

		Plain Graphite Sheet	Graphite Sheet With SS Foil Metal	Graphite Sheet With Tanged Metal
Insert Material		-	Stainless Steel Foil	Tanged Matel
Max Temperature	English	900ºF	900ºF	900ºF
	Metric	480ºC	480ºC	480ºC
Max Service Pressure		1500 psi	2000 psi	2000 psi
Compressibility		49%	35%	35%
Recovery Minimum		15%	17%	17%
Creep Relaxation		4%	4%	4%
Ash Content		<1%	<1%	<1%
Carbon Content		95-99%	95-99%	95-99%
Density	English	70 lb/ft3	70 lb/ft3	70 lb/ft3
	Metric	1.12 g/cm3	1.12 g/cm3	1.12 g/cm3
Thickness	English	0.024-0.15 in
	Metric	0.8-5 mm
General Size	English	15inX15in, 15inX30 in, 45inX45in
	Metric	500mmX500mm, 500mmX1000mm, 1500X1500mm

Packaging & Shipping
1. Our packaging is as per customer's request.
2. Normal goods delivered by sea transport.
3. Sample shipping by express.
Detailed Photos
Certifications
warehouse or checking
FAQ 1. What is your MOQ?
MOQ may vary by customer's special requirement; we try our best to meet your business requirement.

2. What's your payment terms?
We normally do T/T, and we can also offer western union account for transfer money.
And more flexible payment terms, welcome to have a discuss.

3. Can you provide samples?
A: Yes, we can offer samples, and some samples are free

4. Can you delivery by express?
Yes, we can delivery by any express.

5. When will the sample be ready?
Normally, the sample can be ready in 3 days.

---
