Semi Hermetic Reciprocating Compressor Piston Compressor 10HP/12.5HP/15HP/20HP Low Temperature for Refrigeration Cold Room/Storage

Product Description

Reciprocating Compressor Feature
· LOW SOUND LEVEL
The unique design of the Panasonic compressor* s piston and piston ring reduces the sound level effectively;
With the variable speed motor, the condenser operation mode can be switched between low noise and high efficiency depending on the conditions.
· STANDARDIZATION
With our Chinese and Japanese engineers hardworking in design, testing, and debugging during the last several decades, the angle and fixed position of each bend pipe have achieved the perfect accuracy, and the components selected can match with each other exactly. Moreover, standardization, the inherent strength of the classic quality of Panasonic units, enables the perfect designs reproduced continuously.
· LOW VIBRATION
A resin piston ring imported from Japan is able to reduce vibration and stress with patented technology;
For each unit, the vibration from multiple points units has been tested. With standardization, the design that can get the best test result i applied in each unit.
· ABUNDANT OPTIONAL ACCESSORIES
On the basis of standardization, there are various optional accessories according to national market conditions.
Furthermore, the selection of optional accessories for the central unit can be customer-oriented, such as the addition of a condenser fan control system, removal of the PLC controller, and optional selection of a vibration damper.
· STABLE AND RELIABLE
The machining center in which all the machines are imported from Japan ensures the high quality of Panasonic semi-hermetic piston compressors;
Unit protection devices are completely equipped.
· INTELLIGENT CONTROL
The unit is equipped with an I0T intelligent module as standard;
On the display, unit operating parameters are reported dynamical ly and fault codes are reported when alarming;
Through the mobile APP, the unit running status, running history data, and alarm records can be viewed(new products in 2019).
Capacity comparison of semi-enclosed reciprocating compressors ( Panasonic / Bizer )

HP	Panasonic				HP	Bizer
	Model	Gas Displacement	Cooling Capacity	Cylinders		Model	Gas Displacement	Cooling Capacity	Cylinders
		m³/h	RT	Qty.			m³/h	RT	Qty.
5HP	C-LN37M9A	19.9	2.43	2	5HP	4FES-5	21.78	2.66	4
7.5HP	C-LN55M9A	30.7	3.74	2	7.5HP	4DES-7	32.39	3.95	4
10HP	C-LN75M91	47.6	5.81	4	10HP	4VE-10	41.92	5.11	4
15HP	C-LN113M91	63.4	7.73	4	15HP	4PE-15	58.53	7.14	4
20HP	C-LN150M91	88.7	10.82	4	20HP	4NE-20	67.89	8.28	4
					25HP	4HE-25	88.83	10.83	4
35HP	C-LN250M91	152.1	18.55	6		6HE-28	133.4	16.27	6
					30HP	4GE-30	101.98	12.44	4
						6GE-34	153.0	18.65	6
40HP	C-LN300M91	181.8	22.18	6	40HP	6GE-40	183.0	18.65	6
						6FE-44	183.0	22.31	6
					50HP	6FE-50	183.0	22.31	6

Panasonic/Sanyo Reciprocating Compressor Refrigeration Capacity Table

Serial Number	Specification	MODEL NO	Evaporation temperature(°C)
			-40	-30	-20	-15	-10	-5
Piston compressors	5HP	C-LN37M9A	1,932	3,809	6,010	7,594	9,437	11,507
	7.5HP	C-LN55M9A	3,280	6,130	9,265	11,507	14,023	16,986
	10HP	C-LN75M91	3,960	8,030	13,080	16,680	20,380	25,880
	15HP	C-LN113M91	5,250	11,550	18,500	23,390	29,400	35,430
	20HP	C-LN150M91	9,200	17,700	27,660	34,570	42,700	50,380
	35HP	C-LN250M91	14,990	28,840	45,065	56,323	69,750	82,815
	40HP	C-LN300M91	17,920	34,460	53,853	67,306	83,135	98,964

Bingshan Group was founded in 1930(Investment by Panasonic & Chinese Goverment), there are 43 enterprises, which include 1 public company, 9 subsidiary enterprises (domestically funded enterprises), and 32 Sino-foreign joint ventures. Bingshan Group has total assets of 9.5 billion RMB and 12000 contracted employees. It's China's largest manufacturing base of refrigeration and air-conditioning equipment, agricultural deep processing equipment base, and one of the main bases of China's petrochemical general machinery equipment.

Dalian Bingshan Engineering & Trading Co., Ltd. (Hereafter referred to as BSET) is jointly funded professional trading company by Dalian Bingshan Group Co., Ltd and Dalian Refrigeration Co., Ltd. in 1988. Concentrating on consulting, design, sales.
BSET provides quality products to different application fifields including fruit and vegetable, meat and poultry, seafood, beverage etc processing and freezing & refrigerating fifield etc.
BSET has undertaken hundreds of turnkey projects in Asia, Africa, America etc. more than 60 countries and regions, as well as offer customized energy optimization and sustainable cold chain solutions.

Main Application
Heating Ventilation Central Air Conditioning
Industrial Refrigeration
Food Refrigeration
Trading & Service
OEM & PART

Main Products
Screw Compressor Unit Series
Piston Compressor Unit Series
LiBr Absorption Chiller Series
Condenser and Cooling Tower Series
Evaporator Series
Quick Freezer Series
Commercial VRF Series, Air Handling Unit Series, Terminal Equipment Series



FAQ:
Q1.What is our main product?
A1: Our company is a professional trading company funded by Dalian Refrigeration Co., Ltd. in 1988. Concentrate on consulting, design, sales, installation, commissioning, and maintenance of the refrigeration equipment.

Q2.When can I get the price?
A2:We usually offer the quotation within 2-3 work days for equipment and 5-10 work days for the system after receiving your inquiry. For urgent offer, please contact with us for special.

Q3.What is the Trade Term?
A3: We accept Ex-work factory, FOB Dalian, CNF or CIF, as your requirement.

Q4.How long is our Production leading time?
A4: It depends on the type of equipment.
For cold storage equipment, the lead time is 60-80 days after receiving the down payment or Letter of credit.
For Spiral Freezer, Tunnel Freezer, the lead time is 80-90 days after receiving down payment or Letter of credit.
For the flake ice making unit and plate freezer, the lead time is 45 days after receiving down payment or letter of credit.

Q5.What is the Payment term?
A5: By 100% T/T before shipment or By L/C at sight.

Q6. During shipping, if there is damage to products, how do you get a replacement?
A6: Firstly, we should investigate the reason cause the damage. At the same time, we will claim for the insurance by ourselves or assist the buyer.
Secondly, we will send the replacement to the buyer. The responsible person for the above damage will take charge of the cost of the replacement.

Q7. What are your terms of packing?
A7: Packing: export-worthy package suitable for container transportation.

Q8. Do you test all your goods before delivery?
A8: Yes, we have 100% test before delivery.

Q9: How do you make our business long-term and good relationship?
A9: Dalian Refrigeration Co., Ltd was established on 1930. In past 88 years, we have set up our famous brand "Bingshan" not only in domestic market but also overseas market. How to make this brand life so long time? Good quality and reliable service create good reputation among the customers. Many customers keep adopting our system in past 20days extension of the business. Win-win business is our main task for the long-term cooperation.

Q10: Are you a factory or a trading company?
A10: We are the only door to overseas market for Dalian Refrigeration Co., Ltd. We have our own design team, installation team and after-sales team. We are professional engineering & trading company. We have set up branch office in Philippines, Malaysia, Thailand, Burma, Cambodia, Singapore, Bangladesh, Pakistan, Russian, Uzbekistan, Brazil, Argentina etc.

Q11: Where is your factory located?
A11: Our factory is located in Dalian, Liaoning province.

Q12: What is your warranty?
A12: Warranty: 12months after commercial running or 18months from the date of shipment, subject to the earlier expiry.

Q13: Can you arrange thirty party pre-shipment inspection
A13: Pre-shipment inspection: Supplier's pre-shipment inspection is Final; pre-shipment inspection by third Party on buyers cost.

Q14:Can we do our OEM logo?
A14:Yes, for the products with drawing supplied by you, we of course apply your logo

---
