Two-Step Speed Button Industrial Radio Remote Control for Crane and Hoist

Product Description

Product Description
Product Specifications : 12V UHF : The Receiver power supply 12V AC DC . Frequency UHF 425~446MHz . Arrow buttons
18-65V UHF : The Receiver power supply 18-65V AC DC . Frequency UHF 425~446MHz . Arrow buttons
65-440V UHF : The Receiver power supply 65-440V AC DC . Frequency UHF 425~446MHz . Arrow buttons
F24-6D Function Characteristic :
1.Have 7 function keys (6 double speed buttons + 1 start button ).
2. Control contact is up to 12.
3. With mushroom head rotation scram button
4. Safety switch key is to prevent from unauthorized user
5. With battery voltage warning device, the power supply is cut off during low power.
6. Program the button function by computer software.( The program software /data line need to buy extra )
7. Up/down, east/west, south/north can be programmed to interlock or non-interlock, toggle or normal etc. Start button can be program to be start, normal, toggle function etc.
F24-6D Standard Configuration:
1 pieces transmitters (with hanging belt)
1 piece receiver with 1.5M cable connector
1 pieces dust bag
1 piece english manual Product Details
Product Advantages
Product Parameters

Transmitter Parameters: F24. -TX
Material	Glass-Fiber PA
Enclosure protection class	IP65
Frequency range	VHF: 310~331 MHz; UHF: 425~446MHz
Transmitter power	≤10dBm
Transmitter power supply	2 AA batteries
Safety code	32 bits (4.3 billion)
Temperature range	- 40ºC~+85ºC
Control distance	Approx 100m (200 meters is customized)
Receiver Parameters: F24-RXC
Material	Glass -Fiber PA
Enclosure protection class	IP65
Frequency range	VHF: 310~331MHz; UHF: 425~446MHz
Receiver sensitivity	-110dBm
Receiver power supply	18~65V AC/DC / 65~440V AC/DC ( optional )
Output contactor capacity	8A sealed relay output (with AC 250V/10A relays, 10A fuse)
Control distance	Approx 100m (200 meters is customized)
Safety code	32 bits (4.3 billion)
Temperature range	- 40ºC~+85ºC
