Basic Info.
Column number
Four Column
Automatic Grade
Automatic
Depth of Sheet Material
PS/PVC: 0.10mm-0.80mm Pet: 0.10mm-0.60mm
Production Rate
15-30die/Min
Transport Package
Wooden Packaging
Specification
size: 500mm*350mm
Production Capacity
5sets/Month
Product Description
Plastic Fruit Vegetable Crate Container Making Molding Machine Factory Supplier Manufacturer
Model-500 thermoforming machine is a new type of machine developed by our company according to the market and customer's demand. The machine is a kind of multi-station automatic machine, which has the synchronous complete forming, punching, and cutting, so easy to get the end plastic products. Therefore, the input of labor and the cost of production is greatly reduced, and the work efficiency is much more improved. It can be applied to metal, food, medicine, cosmetics and other PP,/PLA/ BOPS/PS/PET/PVC plastic products.
| Model | MODEL-PP500 |
| Suitable Sheet | PP, PLA, BOPS, PVC, PS, PET,etc. |
| Largest Forming Area | 500mm*400mm |
| Maximum Width | 520mm |
| Maximum Depth | 80mm |
| Power | 52Kw |
| Air Pressure | 0.6-0.8Mpa |
| Production rate | 15-30die/min |
| Depth of Sheet Material | 0.10mm-1.20mm |
| Weight | 3800Kgs |
| Overall Dimension | 4900mm*2000mm*2200mm(L*W*H) |
Sample:
Our service:
1. warranty: 12months. if the spare part is broken in the warranty period, we will send a free replacement part as free.
2. Installation and training: we can send engineer to install and run the machine, but all the charges should be paid by buyer, as visa, two-way tickets, meals and accommodation, etc.
3. Quotation: valid for 30days.
Specialist:
Compact structure, stable operation, simple operation, convenient maintenance;
Servo adjustment, interface touching screen;
Adjustable moving-trip, mould replacement is simple;
According to user requirements design mold;
>>
