R88M-G75030T-BS2 OMRON CNC Control Machine Rotary Servo Motor

Product Details

Product Description

Product Description
Brand:Model:Origin:High Light:

OMRON	R88M-G75030T-BS2
China
ewing machine servo motor,electric servo motor

R88M-G75030T-BS2 OMRON AC Servomotor , With ABS/INC Encoder 750W , 200 VAC , With Key / With Brake , 3000rpm
200-VAC Input Power
Model (R88M-)G05030HG10030HG20030HG40030HG75030HItemUnitG05030TG10030TG20030TG40030TG75030TRated output t * 1WRated torque * 1N·mRated rotation speedr/minMax. momentary rotation speedr/minMax. momentary torque * 1N·mRated current * 1A (rms)Max. momentary current * 1A (rms)Rotor inertiakg·m2
(GD2/4)Applicable load inertia---Torque constant * 1N·m/APower rate * 1kW/sMechanical time constantmsElectrical time constantmsAllowable radial load *3NAllowable thrust load *3NWeightWithout brakekgWith brakekgRadiation shield dimensions (material)Applicable Servo Drives (R88D-)Brake
specifi-
cationsBrake inertiakg·m2
(GD2/4)Excitation voltage *4VPower consumption
(at 20 °C)WCurrent consumption
(at 20 °C)AStatic friction torqueN·mAttraction time *5msRelease time *5msBacklash
Allowable work per
brakingJAllowable total workJAllowable angular
accelerationrad/s2Brake life---Rating---Insulation grade---

50	100	200	400	750
0.16	0.32	0.64	1.3	2.4
3000
5000				4500
0.45	0.90	1.78	3.67	7.05
1.1	1.1	1.6	2.6	4
3.4	3.4	4.9	7.9	12.1
2.5 × 10-6	5.1 × 10-6	1.4 × 10-5	2.6 × 10-5	8.7 × 10-5
30 times the rotor inertia max. *2				20 times the rotor inertia max. *2
0.14	0.19	0.41	0.51	0.64
10.4	20.1	30.3	62.5	66
1.56	1.1	0.71	0.52	0.45
0.7	0.79	2.6	3	4.6
68	68	245	245	392
58	58	98	98	147
Approx. 0.3	Approx. 0.5	Approx. 0.8	Approx. 1.2	Approx. 2.3
Approx. 0.5	Approx. 0.7	Approx. 1.3	Approx. 1.7	Approx. 3.1
100 × 80 × t10 (AI)		130 × 120 × t12 (AI)		170 × 160 × t12 (AI)
GT01H	GT01H	GT02H	GT04H	GT08H
2 × 10-7	2 × 10-7	1.8 × 10-6	1.8 × 10-6	7.5 × 10-6
24 VDC ± 5%
7	7	9	9	10
0.3	0.3	0.36	0.36	0.42
0.29 min.	0.29 min.	1.27 min.	1.27 min.	2.45 min.
35 max.	35 max.	50 max.	50 max.	70 max.
20 max.	20 max.	15 max.	15 max.	20 max.
± 1 °
39.2	39.2	137	137	196
4.9 × 103	4.9 × 103	44.1 × 103	44.1 × 103	147 × 103
30,000 max. (Speed of 2,800 r/min or more must not be changed in less than 10 ms)
10,000,000 operations min.
Continuous
Type F

---
