Xrf Cement Analyzer Wdxrf Cement Tester

Product Description

Product Description Instrument introduction
WDX 400 Compact Multi-channel X-Ray Fluorescence Spectrometer features for 10 fixed light diffraction channels, with 10 arbitrary elements defined by the users from Na to U being analyzed simultaneously. The standard ten elements configuration is Na, Mg, Al, Si, S, Cl, K, Ca, Fe, P or Ti(optional). The instrument is an ideal quality control choice for large and medium-sized enterprises.
Higher X-ray power, higher measurement precision, more stable measurement data, higher excitation efficiency, lower limit of detection
Product Parameters Performance characteristics
a. reach adequate measurement accuracy with smaller power and equivalent measurement time;
b. prolonged service life.
c. fewer failures in high voltage supply,
d. lower maintenance costs of the overall instrument,
e. no wearing problem of goniometer as fixed channels adopted.
f. Rapid and non-destructive analysis of powder sample and lump sample
g. Fast analyzer of compacted powder, fused beads and lump material
h. Multi-channel digital MCA has greatly improved the measurement efficiency, which benefits not only the instrument debugging and failure diagnosis but also enhances the measurement accuracy and stability.
Technical specifications
High voltage supply: 400W (50KV8mA)
X-ray tube: 400W thin Be end window X-ray tube made by Varian company, Rh anode (Pd anode optional)
Measurable elements: 10 arbitrary elements from Na to U.
Detector: gas flow proportional detector + sealed proportional detector; 10 paths 1024 channels independent pulse height analyzer
Vacuum system: independent pumping station for easy maintenance with highest vacuum lower than 5 Pa
Gas flow system: high-accuracy gas density stabilizer with pressure stability up to ±0.003 KPa.
MCA: MCA measures the peak of every element in real time, which is not only good for instrument debugging and failure diagnosis but also enhance its analysis accuracy and stability.
AC 220V power supply: 1KVA AC purified stabilized voltage power supply
Analysis accuracy: oη-1 (24 hours,percentage content) ≤0.05 %.
Temperature control precision in constant temperature chamber: setting value+0.1°C.
Standard configurations
400W high-voltage power
400W Be end window X-ray tube
Gas flow proportional detector + sealed proportional detector
10 paths of 1024-channel independent pulse height analyzer
Independent vacuum pumping structure
High sophisticated flow density stabilizer
Multi-channel MCA real-time detection system
1KVA AC purified stabilized current
Application fields
Building materials (cement, glass, ceramic, etc)
Steel
Non-ferrous metals
Minerals,
Geography
Chemical engineering
Petroleum
Quality inspection
Commodity inspection

---
