Metal Cutting Machinery CO2 Laser Machine 3D Acrylic Carving Machine

US$6,900.00-12,500.00 1 Piece (MOQ)

Basic Info.

Model NO.
DLM-1390
Application
Shoemaking Industry, Woodwork Industry, Advertising Industry
Cooling System
Water Cooling
Technical Class
Continuous Wave Laser
Applicable Material
Metal
Structure Type
Gantry Type
Laser Classification
Gaseous Laser
Laser Technology
Laser Control Fault Cutting
Working Area
1300mm*900mm
Table
Blade
Laser Power
130W
Controller
DSP
Motor
Stepper
Chiller
Cw5200
Transport Package
Plywood Box
Specification
1300mm*900mm
Trademark
DLM
Origin
China
HS Code
84609090
Production Capacity
1000 Sets/ Year

Product Description

TECHNICAL PARAMETER
Model CO2 Laser Cutter DLM-1390ML
working area 1300mm*900mm
working table blade
working speed <= 400mm/s
laser type sealed CO2 laser tube
laser power 260W
positioning accuracy ±0.05mm ( without red rot)
Image format surpported BMP. PLT. DST. AI. DXF. ETC.
cooling system constant temperature water cooling and protecting system
power supply AC220 ±10% / 50-60HZ
working temprature 0-45ºC
working humidity 5%-95%
smoke exhasusting by funnel
auxilary cutting gas nitrogen, oxygen or air
package Plywood box

Product Features
DLM-1390ML Small Metal&Non-metal Laser Cutter is equiped with co2 laser tube,can be used for cutting metal sheet such as carbon steel,stainless steel and nonmetal materials such as acrylic,die board,MDF,plywood,etc.
Application
Applicable materials: acrylic, stainless steel, carbon steel, MDF,die board.
Application show: metal spectacle frame, furniture plate cutting, MDF photo frame cutting, building model cutting.
