US$600.00-800.00
|
5 SET
(MOQ)
|
Basic Info.
Application Field
Agriculture, Livestock, Aquaculture
Farming Policy
Bed Planting Machinery
Operation
Soil Preparation Machinery, Rotary
Arbor Configuration
Horizontal Axis
Transport Package
Steel Crate or Wood Package
Product Description
Product Description
| MODEL | IGN 90 | IGN 105 | IGN 125 |
| Structure Weight | 250kg | 265kg | 285kg |
| Tilling Width | 895mm | 1045mm | 1245mm |
| Tilling Depth | 150mm | 150mm | 150mm |
| No. Of Blade | 18 | 24 | 30 |
| PTO Turning Speed | 540r/min | 540r/min | 540r/min |
| Tractor HP | 16-20hp | 20-28hp | 25-30hp |
| MODEL | IGN 135 | IGN 150 | IGN 180 |
| Structure Weight | 300kg | 320kg | 350kg |
| Tilling Width | 1345mm | 1495mm | 1795mm |
| Tilling Depth | 150mm | 150mm | 150mm |
| No. Of Blade | 30 | 36 | 42 |
| PTO Turning Speed | 540r/min | 540r/min | 540r/min |
| Tractor HP | 25-30hp | 30-50hp | 40-75hp |
Rotary tillers manufactured by Breviglieri are all PTO-driven and are used to loosen and mix both firm soil, during primary tillage, and tilled soil (e.g. during secondary tillage to prepare the seed bed).
The tilling implements, which can consist of hoe, radial blade or spike assemblies mounted on a horizontal rotor (4 or 6 per flange), work by cutting and ripping clods of soil.
Rotary tiller cultivation can be performed as an alternative to plowing. It is useful in that it effectively breaks up the earth, even uprooting crop residue, and therefore generally eliminates the need for additional soil preparation.
These machines are most widely utilized in the horticulture sector and on naturally loose ground; the working depth is generally not greater than 15 cm.
Packaging & Shipping
Our Advantages
We have a whole complete set of production equipment, so we can shorten the lead time and prices of machine.
We guarantee one year warranty of all our products.
We can produce machines according to any requirements from our customers.
We develop new machines every year.We provide gifts for all of our customers before every year's Christmas.
>>
