Farming Chicken for Broiler/Poultry Farm/Broiler Chicken House

Product Description

Farming chicken for broiler/Poultry farm/Broiler chicken house
Our equipment for poultry including the following five aspects :

1.Main feed delivery system ,
2.Auto pan feeding system ,
3.Auto Water nipple drinking system ,
4.Tunnel ventilation system ,
5.Environment control system.
Below is equipment for poultry layout:
1.Main feed delivery system
The main feed delivery system is used to delivery feed from silo to the sub hopper of feedingline in the poultry house.
There are two kinds of silo for your option (275g/m2 and Glass fiber reinforced plastic)
If you want save cost for invest , you can use a indoor bigger hopper instead of silo .
Silo parameter ( hot galvanized stee silo )

Model	diameter (mm)	Volume(m3)	Capacity(ton )	Height (meter)
1	1834	4.4	2.8	4.1
2	1834	6.8	4.4	5
3	1834	9.2	6	5.9
1	2750	11.7	7.6	4.7
2	2750	16.9	11	5.6
3	2750	22.1	14.3	6.5
1	3668	24.5	16	5.7
2	3668	33.8	22	6.6
3	3668	43.1	28	7.5
power	voltage	frequency	phase	current
0.75kw/1.1kw/1.5kw	220v/380v	50HZ/60HZ	Triple/single	AC

2.Auto broiler pan feeding system:

1). Our Broiler farm pan feeding system consists of hopper, motor, feed pipe and auger and haning system .
2). Therer are two kinds of pan feeding system for your option A and B .
3).Broiler feedingline Specification : 3-4 pans per 3 meters , feed pipe diameter: ø45mm, hot gavalnized steep pipe
4).Feed pan capacity : 45-55 birds /pan
5). Technical System auger from south africa

3.Auto water nipple drinking system

1).Our broiler water nipple drinking system consist of water front parts, nipple drinking line , hanging system, regulator and water line end parts.
2).Water Level Display Height:

Chicken Age (days)	1-7days	8-14days	More than 15 days
Water Level Height of display Tube (mm)	50-80mm	80-200mm	200-350mm

3). Nipple drinker capacity : 8-12 birds/ nipple
4). We have two kind of broiler water drinking system(Plasson drinking system and Lubing drinking system) for your choice ..
4.Tunnel Ventilation system:

1) 50 inch ventilation fan : box fan or cone fan
The fan has accredited Europe of CE certification.
The guarantee period is one year,during which the easily damaged parts are offered free of charge.

Description	Blade Diameter (mm)	Frequency (Hz)	Current (A)	Input Power (KW)	Voltage (V)	Rotational Speed (r/min)	Airflow (m3/h)	Size(mm)	Weight (Kg)
50" box fan	1270(50inch)	50	2.8	1.1	380	1440	43170	1380*1380*450	89
50 cone fan	1270(50inch)	50	2.8	1.1	380	1440	51020	1380*1380*1360	100

Evaporation Water cooling pad system : It is best effecitive combiation to decrease the temperature in poultry house in hot cliamte area .
Water cooling pad curtain of broiler poultry farming equipment
Coling Paper Size : length : 1.5 m ,1.8m , 2.0 m width:0.6m. thickness : 0.15m
Size with aluminum allloy frame : 1.66m ,1.96 m ,2.16 m
The best air speed getting trough water cooling pad is 1.8 meter /second .

5.Environment control system

1). Environment controller
Agrologic 610 , Agrologic 616 , Rotem AC2000, AC2000 PLUS for your option .
control box :Germany brand or China brand

2). Cooling pad system:
The longitudinal way of cooling-fan ventilation way is the most economical and effective way to reduce temperature of chicken house in summer.

3). Spraying system (Fogging system)
This system effectively cools, humidifies, dedusts and disinfects the henhouse(the temerature is quickly reduced by 3-8 degrees centigrade within a few minutes).

4). Heating system
We can offer gas brooder , diesel heater ,gas heater and hot blast heater..
Our Service:
1. Poutlry farm design and construction
2. Offer CAD layout drawing
3. Installation : two installation engineers will be sent to farm site guid installtion and give training for equipment operation
Our warranty :
1. all plastic products are made of virgin raw material such as the feed pan , water drip cup ,clips , air inlet 15 years 2. Nipples : 10 years
3.The accesorries such as the bolts ,nuts ,pulley ,water winch ,rope clips are stainless steel
4. Feed motors from Italy brand Transtechno
5. Auger from South Africa technical system
6. Feed sensor from Germany
7. Control box :Germany brand or China brand
We also can provide you overvalue services :( one -stop service for poultry farm needs )
1. Poultry House site Selection
2. Poultry House Design and Construction Preparation Guidance.
3. poultry house construction
4. Breeding Equipment Installation and guid operation
Common FAQ for equipment for poultry quotaiton:

1. What information you are supposed to provide to get a good price?
a. Chicken farm size (Length*width*height);
b. Quantity of chickens in one farm;
c. Weight of chickens when they're for sale in market;
d. Chicken farm location and local climate condition (temperature, humidity...);

2. payment details:
we can accept T.T ,30% Down payment and the balance Paid by T/T OR L/C before Shipment

3. Delivery time :
15-20 days after deposite

---
