| Genie S-65 XC Specifications | ||
| Measurements | Metric | US |
| Working height maximum | 21.81 m | 71ft |
| Platform height maximum | 19.81m | 65ft |
| Horizontal reach maximum | 16.51m | 54ft 2in |
| Below ground reach | 2.65m | 8ft 8in |
| Productivity | ||
| Maximum lift capacity - unrestricted | 300kg | 66lbs |
| Maximun lift capacity -restricted | 454kg | 1000lbs |
| Platform rotation | 160° | 160° |
| Vertical jib rotation | 133° (+ 79° /- 54°) | |
| Turntable rotation | 360° continuous | |
| Turntable tailswing | 1.41 m | 4 ft 7.5 in |
| Drive speed - stowed | 4.8 km/h | 3.0 mph |
| Drive speed - raised/extended | 0.3 m/s | 1 ft/s |
| Gradeability - stowed | 45% | 45% |
| Turning radius - inside | 2.40 m | 7 ft 9 in |
| Turing radius - outside | 5.50 m | 18 ft 2 in |
| Controls | 12V DC proportional | |
| Tyres | 355/55D 625 | |
| Power | ||
| Power source | Deutz D2011L03i, 48 hp (36 kW) | |
| Auxiliary power unit | 12V DC | 12V DC |
| Hydraulic tank capacity | 170 L | 45 gal |
| Fuel tank capacity - diesel | 132 L | 35 gal |
