Klt-X9mf-Ov5640-1b V1.2 WiFi Camera 5MP Ov5640-1b Mipi and Dvp Parallel Interface M12 Fixed Focus Camera Module

Product Description

5MP OV5640-1B MIPI and DVP Parallel Interface M12 Fixed Focus Camera Module
Camera Module No. KLT-X9MF-OV5640-1B V1.2

Camera Module No.	KLT-X9MF-OV5640-1B V1.2
Resolution	5MP
Image Sensor	OV5640-1B
Sensor Type	1/4"
Pixel Size	1.4 um x 1.4 um
EFL	0.90 mm
F.NO	2.00
Pixel	2592 x 1944
View Angle	220.0°(DFOV) 187.0°(HFOV) 144.0°(VFOV)
Lens Dimensions	13.00 x 13.00 x 13.56 mm
Module Size	55.00 x 22.00 mm
Module Type	Fixed Focus
Interface	MIPI and DVP Parallel
Auto Focus VCM Driver IC	Embedded
Lens Model	KLT-LENS-TRC-F5022A6-02
Lens Type	650nm IR Cut
Operating Temperature	-30°C to +70°C
Mating Connector	FX12B-40P-0.4SV
