High Capacity Mobile Crusher, Mobile Crusher Plant for Sale, Price for Mobile Crushing Plant

Product Description

Different Colors&Packages are available
High Capacity Mobile Crusher, Mobile Crusher Plant For Sale, Price for Mobile Crushing plant
Mobile crusher, also called mobile crusher plant, mobile stone crusher, mobile crushing plant or mobile stone crusher.This mobile crusher is an integrated machine of vibrating feeder, stone crusher, vibrating screen and other auxiliary equipments.So mobile crusher is a mobile stone crushing plant in fact. The mobility of mobile crusher can overcome the limited by the crushing place, and reduces high material transportation cost meanwhile.


Mobile crusher has several types. In terms of the stone crusher types, mobile crusher plant can be divided into three types: mobile jaw crusher, mobile cone crusher and mobile impact crusher. Mibile jaw crusher is used for primary crushing and the other two are used for fine crushing. Each mobile crusher plant can work as a whole complete individual. But there are some special mobile crushers, which a machine body inculdes a complete crushing plant. A mobile crusher plant like this can offord the whole complete crushing plant.

Mobile crusher can crush materials on site or working nearly. It is widely used in the industry of mining, metallurgy, building materials, traffic, water conservancy and so on.


High Capacity Mobile Crusher, Mobile Crusher Plant For Sale, Price for Mobile Crushing plant Features

1.Move easily. Mobile crusher can go to the crushing place directly. It can move not only on the smooth road, but also on the bumpy road.

2.Compact structure and simple operation. Integrative equipment group with trailer save the working area. With generator, motor and control box on the trailer, Mobile crusher plant can work outdoor easily. Equipped with supporting facilities, it can be installed quickly and conveniently.

3.Save the cost. By crushing the materials on site, the transportation cost of mobile crusher is reduced.

4.Wide applicability
. The mobile crusher plant can work as independent unit or work with other units to form a primary-secondary crushing system or primary-secondary-fine crushing system. It can also work as a production line with the screening equipment according to the requirement of customers (firstly screening then crushing, or firstly crushing then screening).

5.Stable performance and convenient maintenance. Equipped with crushers, vibrating feeders, and vibrating screens designed by Great Wall Heavy Industry Machinery, the mobile crusher shows high quality and reliable performance. Materials are delivered by belt conveyors, which is simple to operate and easy to maintain. The machine is featured by low investment and high production efficiency.

6.Flexible configuration. Mobile crusher can be customized according to customers' requirement on working site, materials and particle shape. Examples of customized machines include single units, combined units, units with self-discharged belt conveyors.


High Capacity Mobile Crusher, Mobile Crusher Plant For Sale, Price for Mobile Crushing plant Main Specifications

Mobile Cone Crusher Main Specifications and Pictures

Model	Vibrating screen	Cone crusher	Belt conveyor	Configuration of wheels	Capacity (t/h)	Overall Dimension (mm)	Weight (t)
Y3S1548Y900	3YZS1548	PY900	B650×7M	Dual-axle	30-90	13700×2800×5700	34
Y3S1848S36	3YZS1848	CZS36	B650×7M	Dual-axle	45-165	13700×3150×5700	39
Y3S1860S51	3YZS1860	CZS51	B800×8M	Tri-axle	80-350	15200×3150×6400	55
Y3S2160H220	3YZS2160	HP220	B1000×8M	Tri-axle	100-430	15200×3500×6450	57

Mobile Imapct Crusher Main Specifications and Pictures

Model	Vibrating screen	Impact crusher	Belt conveyor	Configuration of? wheels	Capacity (t/h)	Overall Dimension (mm)	Weight (t)
Y3S1548F1010	3YZS1548	PF1010	B650×7M	Dual-axle	50-80	12700×2800×5700	35
Y3S1848F1210	3YZS1848	PF1210	B650×7M	Dual-axle	70-130	13500×3150×6000	41
Y3S1860F1214	3YZS1860	PF1214	B800×8M	Tri-axle	90-180	15500×3150×6400	46
Y3S2160F1315	3YZS2160	PF1315	B800×8M	Tri-axle	120-250	16200×3500×6700	57

Mobile Jaw Crusher Main Specifications and Pirctures

Model	Vibrating feeder	Jaw crusher	Belt conveyor	Configuration of wheels	Capacity (t/h)	Overall Dimension (mm)	Weight (t)
YG725E46	GZD750×2500	PE400×600	B650×7M	Single-axle	15-60	10500×2800×3700	25
YG938E57	GZD960×3800	PE500×750	B650×7.5M	Dual-axle	40-100	13000×2900×4100	32
YG938E69	GZD960×3800	PE600×900	B800×8M	Dual-axle	60-140	13200×2900×4600	42
YG1142E710	GZD1100×4200	PE750×1060	B1000×9M	Tri-axle	80-230	15000×2900×5700	55
YG1349E912	GZD1300×4900	PE900×1200	B1200×11M	Quad-axle	140-320	17000×3100×5800	81

The Mobile crusher is fixed tightly when it is sent to the port by professionale truck. Before shipped, it is covered by waterproof material to avoid moisture and rough handling

---
