Constant Tension Green Belt Building Table Rubber Fabric Belt Layers Compress

US$1.00-1,111,111.00 1 Piece (MOQ)

Basic Info.

Model NO.
DCS
Certification
CE, ISO, GOST
Condition
New
Customized
Customized
Automatic Grade
Automatic
Structure
Horizontal
1
1
2
2
3
3
4
4
Transport Package
Wooden Case
Specification
STANDARD CONTAINER
Trademark
FINEYEAR
Origin
China
HS Code
84778000
Production Capacity
1000 Sets Per Year

Product Description

Conveyor belt constant tension laminating machine
1.Usage: For laminating and preforming of fabric rubber conveyor belt.
2.Technical Parameter:
Main parametrs Type
Forming speed m/min
Max. forming width (mm)
No. of joint layers
Max. roll diameter mm
Control mode
DCS-(1400~1800)
2.5~25
1600
3
3500
PLC+GOT
DCS-(2000~2400)
2.5~25
2200
3
3500
PLC+GOT
DCS-(2400~3200)
2.5~25
3000
3
3500
PLC+GOT
3.Feature:
1). Production line use PLC control. This production line adopts a technology which combines vector variable frequency control and intelligent tension let off. This technology will give intelligent control for constant tension in the production.
2). Production line use EPS auto correction technology which features fast response and precisely positioning control.
3). To avoid safety accident, production line has complete safety measures, workers are able to stop the production line immediately at any operating point.
FINEYEAR specializes in developing and manufacturing high quality conveyor belt constant tension laminating machine, which is one of the best and professional manufacturers of various high quality machinery. We have a productive factory, welcome to wholesale quality conveyor belt constant tension laminating machine at cheap price with us.
Hot Tags: conveyor belt constant tension laminating machine China, manufacturers, factory, wholesale, cheap, rubber conveyer belt production line

Applicable rubber sheet specification (TxW) (mm)
(4-12)x600 (900)

Power supply (V/HZ)
380/50

Compressed air pressure (Mpa)
0.4-0.8

Max. Speed of picking up conveying belt (m/min)
40

Moving speed of hanging rubber rod (m/min)
0.117-0.75

Max. height of hanging sheet (mm)
1400
(KWXPCS)
Cooling fan FTA&capacity
final mixing: 0.37x48 master batch: 0.37x60
()
Swing sheet frequency (adjustable) (m)
1.3

Swing sheet frequency (m/min)
13
()
Temperature of rubber sheet (for reference)
5
Ambient temperature+5°

Cooling reducer motor
XWD1.1-4-1/29

Lift reducer motor
XWD2.2-6-1/35

Hanging rod reducer motor
XWD5.5-85-1/595

Conveyor reducer motor
XWD3-5-1/23

Down swing sheet reducer motor
XWD1.1-5-1/87
