Diamond Grinding Wheel Fitting for Glass
US$60.00
5-49
Pieces
US$58.00
50-99
Pieces
US$56.00
100-499
Pieces
US$53.00
500+
Pieces
Basic Info.
Model NO.
GW9
Bonding Agent
Metal
Diameter
200mm
Thickness
30mm
Hole Diameter
50
Diamond Grit
100#
Type of Technical
Hot Press
Transport Package
Carton
Specification
200
Trademark
RECO
Origin
China
HS Code
8207201000
Production Capacity
50000PCS/Year
Packaging & Delivery
Package Size
21.00cm * 21.00cm * 3.00cm
Package Gross Weight
2.000kg
Product Description
Diameter(mm)
Hole(mm)
Thickness(mm)
Diamond grit
Work part(mm)
Kind of grinding
200
50
30
100
7x3.2
Rough grinding
Diamond grinding wheel is one kind of diamond tools. It is mainly suitable for all kinds of refractory surface grinding processing. The product adopts a specially designed conical mounting structure, making it easy to load and unload. It has the advantages of good machining flatness, high grinding efficiency and long service life. It is made of diamond cutter head welded or cold pressed on the metal matrix. The diamond cutter head is made by sintering artificial industrial diamond and other metal powder.
This kind of diamond grinding wheel is used for solar glass, auto glass, electronic glass, super thin glass grinding.
They are produced by the newest Vacuum-Hot pressing sintering machine. As the temperature of the hot pressing sintering is 800ºC~1000ºC, the high vacuum can make the diamond grit just a tiny injury. There will be no oxidation of the diamond grit in the hot pressing sintering.
This kind of diamond grinding wheel has good sharpness and long service life.
The edge surface of glass will be better after grinding.
Have a try and you will love it!
Customization is available on request.
>>
