ISO9001 Certified Liquid Solid Centrifuge Separator

Product Description

Changzhou Qianmai Mechanical Equipment Technology Co., Ltd (CHM) is a leading company specializing in the development, testing, manufacturing, sales, and after-sales support of disc separators. Our team of experts, with over 30 years of experience, can tailor separation solutions for customers in the pharmaceutical, biomedicine, and biochemical industries. We offer timely preventive maintenance, troubleshooting, repair, machine refurbishment, and upgrade services to ensure optimal performance and efficiency.
Working Principle of Separator In the suspended liquid, multiple phase materials with different densities and indissolubilization obtain different sedimentation rates in the centrifugal force field. Based on this principle, rapidly rotating the disc stake can generate a great G force & more great equivalent sedimentation area, which the differential phase materials can be separated in a short time.
Company name: Changzhou Qianmai Mechanical Equipment Technology Co., Ltd
Disc Separator by Changzhou Qianmai Mechanical Equipment Technology Co., Ltd
Our disc separator offers numerous advantages over traditional methods:

No filter media consumption, eliminating secondary pollution
Continuous and stable operation
Fast processing speed
Effective treatment
Low energy consumption
Moderate capacity
SIP and CIP functions
Small footprint
Low operating cost
High automation, reliable operation, and low labor intensity

Check out the Disc Separator separation module system diagram for a better understanding of its operation.
Product Description
Product Description:
Company Name: Changzhou Qianmai Mechanical Equipment Technology Co., Ltd
The separator from Changzhou Qianmai efficiently handles the separation of liquid/liquid/solid three-phase and liquid/solid two-phase materials. It can separate non-emulsified liquid particles as small as 2μm and solid particles (including cell debris) smaller than 0.5 microns with a density above 1.02g/ml.
Cell Collection Equipment for Fermented Drugs Changzhou Qianmai Mechanical Equipment Technology Co., Ltd offers DFBS and DQBS series models designed for the biological fermentation industry. These models are tailored to meet GMP and CIP/SIP requirements, ensuring high efficiency and stability with a separation G force of up to 14500G. The equipment can be customized for single or modular design based on demand.
Features:
Meets GMP requirements and CIP/SIP standards
High separation efficiency with a G force of 14500G
Customizable design options

Typical Applications:
Concentration and clarification of fermented mash (e.g., escherichia coli, bacillus, probiotics)
Extraction of vitamins, antibiotics, hormones
Collection of microbial cells
Extraction of blood products components
Separation and concentration of yeast
Processing Chinese medicine extracts, pharmaceutical intermediates, synthetic pharmaceutical products
Extraction and separation in genetic engineering

Trust Changzhou Qianmai Mechanical Equipment Technology Co., Ltd for reliable and efficient cell collection equipment for your fermentation processes.
Product Parameters

Model	Treatment Capacity (L/H)	Motor Power (KW)	Inlet Pressure (MPa)	Outlet Pressure (MPa)	Weight (KG)	Overall Dimensions (mm)
DFBS260	200-500	2.2	0.05-0.1	≤0.3	260	620*510*1400
DQBS260	700-1500	3	0.05-0.1	≤0.3	280	620*510*1400
DQBS350	1200-2500	5.5	0.05-0.1	≤0.4	450	620*510*1200
DFBS410	2000-4000	11	0.05-0.1	≤0.4	1250	1600*1200*1500
DQBS470	3000-6000	22	0.05-0.1	≤0.4	1670	1850*1550*1800
DFBS550	2000-4000	22	0.05-0.1	≤0.4	2100	1980*1610*1950

Detailed Photos Company Profile Packaging & Shipping FAQ
Product Description
Welcome to Changzhou Qianmai Mechanical Equipment Technology Co., Ltd
Product Features:
Manufacturer with over 30 years of experience
Customized services for OEM/ODM
One-stop service from research to upgrade
Flexible payment terms for new and regular customers
Various delivery terms available
Prompt delivery within 3 to 30 working days
1-year warranty with additional instructions for special circumstances
24/7 online after-sales service with expert technical support
Extensive spare parts inventory for quick replacements

Contact Information: For more information, please contact us at Changzhou Qianmai Mechanical Equipment Technology Co., Ltd.

Application	Model	Treatment Capacity	Motor Power	Inlet Pressure	Outlet Pressure	Weight	Overall Dimensions
		(L/H)	(KW)	(MPa)	(MPa)	(KG)	(mm)
Animal Fat/Plant Oil	DQRE260	700-1500	3	0.05-0.1	≤0.3	280	620*500*1100
	DQBE260	1000-2000	3	0.05-0.1	≤0.4	280	620*510*1200
	DFBE350	1200-2500	5.5	0.05-0.1	≤0.4	450	620*510*1200
	DFHE450	3000-4000	11	0.05-0.1	≤0.4	1450	1850*1550*1800
	DFHE610	6000-10000	22	0.05-0.1	≤0.4	2180	1980*1610*1950
Food/Beverage/Dairy	DQRP260	200-500	2.2	0.05-0.1	≤0.3	260	620*510*1400
	DQHN260	700-1500	3	0.05-0.1	≤0.3	260	620*510*1400
	DQBP350	1200-2000	5.5	0.05-0.1	≤0.4	450	620*510*1200
	DQBN380	2000-3500	7.5	0.05-0.1	≤0.4	1250	1600*1200*1500
	DQBN410	2000-4000	11	0.05-0.1	≤0.4	1250	1600*1200*1500
	DQHP510	3000-5000	15	0.05-0.1	≤0.4	1670	1850*1550*1800
	DFHP610	6000-10000	22	0.05-0.1	≤0.4	2100	1980*1610*1950
Biological Fermentation	DFBS260	200-500	2.2	0.05-0.1	≤0.3	260	620*510*1400
	DFBS260	700-1500	3	0.05-0.1	≤0.3	280	620*510*1400
	DFBS350	1200-2500	5.5	0.05-0.1	≤0.4	450	620*510*1200
	DFBS410	2000-4000	11	0.05-0.1	≤0.4	1250	1600*1200*1500
	DFBS510	3000-5000	15	0.05-0.1	≤0.4	1670	1850*1550*1800
	DFBS610	6000-10000	22	0.05-0.1	≤0.4	2100	1980*1610*1950
Industrial Waste Liquid	DFBY200	200-1000	0.37	0.05-0.1	≤0.3	80	500*600*1200
	DFBY260	700-1500	3	0.05-0.1	≤0.3	260	620*510*1400
	DFBY260	1000-2000	3	0.05-0.1	≤0.4	280	620*510*1200
	DFBY350	2000-3000	5.5	0.05-0.1	≤0.4	450	620*510*1200
	DFBY410	3000-4000	11	0.05-0.1	≤0.4	1600	1850*1550*1800
Chemical Liquid Coal Tar Marine/Mineral Oil	DFBY510	3000-5000	15	0.05-0.1	≤0.4	1670	1850*1550*1800
	DFHY610	6000-10000	22	0.05-0.1	≤0.4	2100	1980*1610*1950

---
