| optical performance | |
| brand:Kunguang | |
| monocular or binocular | binocular |
| Magnification | 25X |
| Exit Pupil(mm) | Φ4mm |
| Eye Refilef(mm) | 14mm |
| Eyepiece diameter | 32 |
| FOV | 2°30′(45m/1000m) |
| Resolution | 2.4″ |
| lens diameter | Φ100mm |
| eye distance | 63mm |
| diopter | Fixed lens(∞-0.75) |
| Temperature adaptability | -15 ºC ~ + 50 ºC |
| Horizontal rotation angle | Unlimited, free rotation |
| cabrage | ± 30° |
| Waterproof performance | Outdoor waterproof (IP7) |
| Overall dimensions (host) | 560mm(long)×260mm(w)×247mm(height) |
| total height | 1440mm |
| Net wight weight | 44.7kg |
| packing measurement(s) | Host 560×260×247(16.9kg),base 394×394×100 (16kg) Column 1170×180×180 (11.8kg) |
