10-Port Unmanaged Desktop Ethernet Network Switch with 8-Port Poe Pfs3010-8et-96

Product Description

10-Port Unmanaged Desktop Ethernet Network Switch with 8-Port PoE PFS3010-8ET-96

Product Parameters

10-Port Unmanaged Desktop Switch with 8-Port PoE
> * The parameters and datasheets below can only be applied to V2.0 (version 2.0)
> Intelligent PoE
> 8-pin assignment PoE power supply
> Long distance PoE
> PoE watchdog
> Wide working temperature

Hardware

Data Transmission Port

Port 1-8: 8 × RJ-45 10/100 Mbps (PoE) Port 9-10: 2 × RJ-45 10/100/1000 Mbps (Uplink)

Power Supply

48 V - 57 V DC

Operaing Temperature

-10 °C to +55 °C (+14°F to +131°F)

Operating Humidity

5% - 95% (RH)

Storage Temperature

-20 °C to +70 °C (-4°F to +158°F)

Storage Humidity

5% - 95% (RH)

Power Consumption

Idling: 3 W Full load: 96 W

Performance

Capacity

5.60 Gbps

Packet Forwarding Rate

4.17 Mpps

Packet Buffer Memory

4 Mbit

MAC Table Size

8K

Communication Standard

IEEE802.3/IEEE802.3u/IEEE 802.3ab/IEEE802.3x

PoE

PoE Standard

IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt

PoE Power

96 W

Power Consumption Management

Yes

PoE Pin Assignment

1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)

Long Distance PoE

250 m long distance PoE transmission

PoE Watchdog

Yes

General

Statics Protection

Air discharge: 8 kV Contact discharge: 6 kV

Thunder-proof

Common mode: 4 kV Differential mode: 2 kV

Net Weight

0.50 kg (1.10 lb)

Gross Weight

1.32 kg (2.91 lb)

Product Dimensions

190 mm × 100 mm × 30 mm (7.48" × 3.94" × 1.18")

Company profile

Beswind Technology Limited mainly focuses on the distribution of security products from the three top manufacturers from China-Hikvision, Dahua and Uniview. We have been working in this field since 2010 and we have established long-term and stable relationship with these factories. The products we sell including stand-alone DVR, NVR, IP camera, HDCVI camera, video intercoms, access controls products, alarm products, accessories and so on with international version. We have great advantage on prices and after-sales service amoung the other competitors from China. We adhere to the principle of "Customer Upmost, Service First", so, we always try our best to do win-win business with our customers. We have exported to many countries and regions including Europe, America, Asia, Australia and so on.
OEM orders are acceptable. In addition, we own an purchasing department with professional staff who are professional on sourcing different products for customers who need our help. Your trust is our great honor! Your satisfaction is our pursue. We will continually create new products to satisfy your individual needs. We will make great efforts to offer excellent pre-sales, sales and after-sales service. We are sincerely looking forward to your cooperation!

certificate

Payment / Shipping

FAQ

Q:1.How to confirm whether the product is Dahua and Hikvision genuine English version?
You can download software in the official website of Dahua and Hik vision,only Dahua and Hik vision genuine product is compatible with the software.And we promise all of our products are Dahua and Hikvision genuine products.
Q:2. Do you supply OEM service?
Yes, we are professional OEM/ODM manufacturer and can meet all customized services.
Q:3.What is Minimum Order Quantity?
Sample order is welcomed, while the price is more competitive for big quantity .
Q:4. What is your terms of payment?
A: Usually T/T 30% as deposit, and 70% before delivery. We can accept PayPal and West Union for sample order as well.
Q:5.When will you ship my order?
Ordinary, once we get confirmation for payment,we will ship order within 1-2 days.
Q:6. How do you ship the goods and how long does it take arrive?
For sample order, usually we schedule shipment by DHL, Fedex, UPS or TNT.For bulk order, usually we schedule shipment by air, by sea or by train, and client appointed forwarder and shipment is accepted.
Q:7. Do you test all your goods before delivery?
A: Yes, we have 100% test before deliver
Q:8.How is your after-sale service?
For after-selling service, we will offer free technical training, 24/7 online technical support, and product return for fix service.
Q:9.How about warranty?
Three years warranty.

---
