SMT 2D off-Line Desktop Aoi Saki Bf-Comet 18 Automatic Optical Inspection Machine

Product Description

2D Off Line Benchtop AOI SAKI Comet 18 BenchtopMedium size PCBsResolution 18μmThe 2D-AOI is a high-speed, high-precision 2D visual inspection device that supports multiple inspection processes, such as SMT, and through-hole processes. The extremely durable hardware design guarantees a more stable inspection quality than traditional visual inspection and contributes to significant labor savings at production sites.

System Specifications
Model	BF-Comet10	BF-Comet18
Resolution	10μm	18μm
Board Size	50×50 - 250×330mm, 2×2 - 10×13in.
Board Thickness	0.6 - 2.5mm, 24 - 100mils
Board Warp	+/-2mm, 79mils
PCB Clearance	Top: 40mm, 1.57in. Bottom: 60mm, 2.36in.
Rotated Component Support	Available for 0 - 359° rotation (unit of 1°)
Inspection Categories	Presence/Absence, Misalignment, Tombstone, Reverse, Polarity, Bridge, Foreign material, Absence of solder, Insufficient solder, Lifted lead, Lifted Chip, and Fillet defect. Each defect name can be changed freely by system function.
Tact Time* (250×330mm)	Approx. 18sec.	Approx. 13sec.
Image Scanning Time** (250×330mm)	Approx. 11sec.	Approx. 7sec.
Camera	Line color CCD camera
Lighting	LED lighting system
Operating System	Windows XP English Version
Optional System	BF-Editor / BF-RP1 / BF-View
Optional	2D Barcode Recognition, Journal Printer, OK/NG Signal Out
Optional for BF-Comet18	External Control Box
Installation Specifications
Specification	BF-Comet10	BF-Comet18
Electric Power	Single Phase ~ 100 - 120V / 200 - 240V +/-10%, 50/60Hz
Power Consumption	450VA	400VA
Air Requirement	Not needed
Usage Environment	15°C(59°F) - 30°C(86°F) / 15 - 80%RH (Non-condensing)
Noise Level	56.5dB
Dimensions WxDxH (Main body)	580 × 850 × 452mm, 22.84 × 33.47 × 17.80in.
Weight (Main body)	Approx. 83 Kg, 183lbs	Approx. 80 Kg, 177lbs

Line-Ups for Flexible UseSaki new desktop AOI, BF-Comet, has two models. BF-Comet10 is designed for high density mounting PCB with 01005(0402) chips. It has 10μm resolution and stable scanning unit. BF-Comet18 is designed for high volume manufacturing. It has 18μm resolution and high speed scanning hardware. Both models have newly designed LED lighting unit that enables highest throughput of PCBA inspection.High ThroughputBF-Comet has Saki's original alternate scanning system that captures several lighting images in one scanning. Newly developed color capturing system enable to make scanning speed twice faster than previous model. It takes only 7 seconds to capture M-size board (250mm × 330mm) by BF-Comet18, and 11 seconds with precise 10μm resolution by BF-Comet10. Overall tact time including inspection also become shortened dramatically.New InterfaceRenewed user interface makes it easier to set up inspection data by using pre-installed Saki standard library. And optional new function KPK, that finds out the difference between surface of the board and the surface of component automatically, simplifies to detect missing component. This realizes time reduction for inspection data making at launching production.Advantage of Line Scan Visual InspectionExtra components on the board can be detected only by setting up one inspection window on the whole board. It is realized by the advantage of line scan method.Coaxial Overhead LightSoldering condition is inspected by illuminant irradiation of coaxial overhead lighting. Inspection is not affected by shadowing by neighboring tall components, therefore same library is available at any location on the board.FlexibilityBF-Comet has 40mm clearance at the top side of the board and 60mm at the bottom side. It enables most of the PCBs with tall components. In addition, BF-Comet can be used in any stage of the PCB production process from post-print, post-mounter, and post-flow / re-flow, or manual mounting.Why Choose Us?

Established in 2009, Shenzhen Wenzhan Technology Co., Ltd. has been committed to creating an efficient communication platform to better serve our customers. Our team consists of professional engineers with certifications from the original equipment manufacturers for over a decade. We are dedicated to prioritizing our customers' interests and providing top-quality equipment, accessories, and consumables, as well as technical support. To further reduce our customers' costs, we have established our own machining plant, ensuring ample inventory and competitive pricing.

1. Professional pre-sales advice support 2. Excellent after-sales technical service 3. Flexible payment and return policy 4. One-stop solution for SMT Line 5. Sufficient stock and fast deliver

FAQ

What services do you provide?We are a leading provider of SMT machinary and spare parts in Shenzhen China. We offer a full range of SMT products with OEM and ODM services available.

MOQ?One and mixed order are both welcomed.

What are your payment terms?Pay in full before shipment, either in one lump sum or in installments.

What is your delivery time?We typically deliver within 1 week after receiving full payment.

What if I encounter problems with the machine after receiving it?If you face any issues with the machine during the warranty period, we will send you free replacement parts.

How can I purchase a machine from you?The process is simple and flexible:Consult with us online or via email about the product.Negotiate and confirm the final price, shipping, payment methods, and other terms.We will send you a proforma invoice to confirm your order.Make the payment according to the method specified on the proforma invoice.We will prepare your order and conduct a 100% quality check before shipping.We will send your order by air or sea, based on your preference.

---
