Basic Info.
Processing Accessory
Chuck CNC Lathe
Guide Rail
Horizontal Guide Rail
Tool Holder
Single-tool Holder CNC Lathe
Automatic Grade
Automatic
Certification
GS, CE, RoHS, ISO 9001
Name
Horizontal Heavy Duty CNC Lathe
Max. Turning Length
1000/1500/2000/3000mm
Spindle Bore Diameter
105mm
Tool Turret
Electrical Turret 4 Station
Guideway
Horizontal Hardened Guideway
Tailstock
Manual Tailstock
Hydraulic Chuck
Optional Choice
Transport Package
Wooden Case
Production Capacity
100 Sets Per Month
Packaging & Delivery
Package Size
300.00cm * 200.00cm * 200.00cm
Package Gross Weight
3500.000kg
Product Description
CK6165E High Quality Heavy Duty CNC Lathe Machine Made In China
| Model | CK6165E |
| Max. swing over bed | Φ650 mm |
| Max. swing over cross slide | Φ375 mm |
| Spindle bore | Φ105mm |
| Spindle nose | C11 |
| Spindle speed | 10-85/40-350/110-850 rpm |
| Spindle motor power | 11 kw |
| X/Z axis travel | 400mm, 1100/1600/2100/3100 mm |
| X/Z axis torque | 7.5/10(15) N.m |
| X/Z axis rapid feeding speed | 4/5 m/min |
| X/Z axis position accuracy | 0.005 mm |
| X/Z axis repeatability | 0.005 mm |
| Tool bar section | 32*32 mm |
| Tailstock sleeve dia. | Φ100 mm |
| Tailstock sleeve travel | 250 mm |
| Tailstock taper | MT6 |
| N.W. | 3900/4500/5200/6200 kg |
| Machine dimension | 3500/4000/4500/5500*1900*1900mm |
The CNC Lathe through the numerical CNC control system, this flat bed CNC lath could process different inner bore, ex-circle, circular conical surface and screw thread, especially suitable for the small and middle-sized shaft and plate work piece from rough processing to finish processing in batch. It has advantages like higher automaticity, simpler programming and higher accuracy.
Standard accessories:
Flat bed structure, hardened guideway,
Max.swing over bed 530mm,
Spindle bore diameter 90mm,
Distance between points 1000/1500/2000mm,
Spindle motor power 7.5kw,
Three gears mechanical transmission speed adjustment,
CNC controller GSK,
10 inch manual 3-jaw chuck ,
4-way electric toolpost,
manual tailstock,
automatic coolant system and lubrication system,
work light, tools & Tool box, English operate manual
Optional accessories:
Siemens/Fanuc CNC controller,
Hydraulic chuck,
Hydraulic tailstock,
6/8-station turret,
>>
